Vertex Standard VXR-7000 Service Manual

37VXR-7000 UHF Service Manual
PCB with Components Not Supply
C 1501 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B i2
C 1503 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 1- B i2
C 1504 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B i2
C 1505 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B i2
C 1506 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B i2
C 1507 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 1-17 A A2
C 1507 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 VERS. A 18- A A2
C 1507 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 VERS. D 18- A A2
C 1508 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 1-17 A A2
C 1508 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 VERS. A 18- A A2
C 1508 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 VERS. D 18- A A2
C 1509 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1-18 B h2
C 1509 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VERS. A 19- B h2
C 1509 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 VERS. D, Ex. EIA (CE) 19- B h2
C 1509 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 VERS. D, EIA (CE) 19- B h2
C 1511 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B h2
C 1512 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B h3
C 1513 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 1- B h2
C 1514 CHIP CAP. 0.01uF 50V B GRM216B11H103KA01D K22170817 1- B h2
C 1515 CHIP CAP. 1uF 25V W5R CM32W5R105K25AT K22145801 1-17 A B2
C 1515 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 18- A B2
C 1516 CHIP CAP. 1uF 10V B GRM21BB11A105KA01L K22100802 1- B h2
C 1517 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B h2
C 1518 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 1- B g2
C 1519 CHIP CAP. 0.01uF 50V B GRM216B11H103KA01D K22170817 1- B g2
C 1520 CHIP CAP. 1uF 25V W5R CM32W5R105K25AT K22145801 1-17 A B2
C 1520 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 18- A B2
C 1522 CHIP CAP. 9pF 500V CH GRM42-6CH090D500PT K22271212 1-17 A D1
C 1522 CHIP CAP. 18pF 500V CH GRM42-6CH180J500PT K22271219 VERS. A 18 A D1
C 1522 CHIP CAP. 22pF 500V CH GRM42-6CH220J500PT K22271221 VERS. A 19- A D1
C 1522 CHIP CAP. 9pF 500V CH GRM42-6CH090D500PT K22271212 VERS. D 18- A D1
C 1523 FILM CAP. 68pF 500V UC232H0680J-T K33279030 1- A D2
C 1524 CHIP CAP. 0.001uF 50V B GRM216B11H102KA01D K22170805 1- A C2
C 1525 CHIP CAP. 10pF 500V CH ERE22X6C2H100JD01L K22273217 VERS. A 18 A D2
C 1525 CHIP CAP. 22pF 500V CH ERF22X6C2H220JD01L K22273209 VERS. A 19-30 A D2
C 1525 CHIP CAP. 22pF 500V CH ERF22X6C2H220JD01L K22273209 VERS. A, Ex. EIA (CE) 31- A D2
C 1525 FILM CAP. 12pF 500V UC232H0120J-T K33279020 VERS. A, EIA (CE) 31- A D2
C 1526 CHIP CAP. 33pF 500V CG C17CG330K4TXLT K22273235 1- A E2
C 1527 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- A B2
C 1528 CHIP CAP. 39pF 500V CG C17CG390K4TXLT K22273236 1- A E2
C 1529 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A B3
C 1530 CHIP CAP. 39pF 500V CG C17CG390K4TXLT K22273236 1- A E2
C 1531 CHIP CAP. 47pF 500V CG C17CG470J4TXLT K22273240 1-17 A E2
C 1531 CHIP CAP. 33pF 500V CG C17CG330K4TXLT K22273235 VERS. A 18- A E2
C 1531 CHIP CAP. 47pF 500V CG C17CG470J4TXLT K22273240 VERS. D 18 A E2
C 1531 CHIP CAP. 47pF 500V CG ATC700B470KW500XT K22273242 VERS. D, Ex. EIA (CE) 19- A E2
C 1531 CHIP CAP. 33pF 500V CG C17CG330K4TXLT K22273235 VERS. D, EIA (CE) 19- A E2
C 1532 CHIP CAP. 10pF 500V CH ERE22X6C2H100JD01L K22273217 1-18 A E2
C 1532 CHIP CAP. 10pF 500V CH ERE22X6C2H100JD01L K22273217 VERS. D 19- A E2
C 1532 CHIP CAP. 10pF 500V CH ERE22X6C2H100JD01L K22273217 VERS. D, Ex. EIA (CE) 19- A E2
C 1532 FILM CAP. 12pF 500V UC232H0120J-T K33279020 VERS. D, EIA (CE) 19- A E2
C 1533 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B h2
C 1534 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A D1
C 1535 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A G1
C 1536 AL.ELECTRO.CAP. 1000uF 25V RJ3-25V102MI5# K40149041 1- A G1
C 1537 CHIP CAP. 0.001uF 500V W5R GRM42-6W5R102K500PT K22271801 1- B d1
C 1538 CHIP CAP. 0.01uF 200V X7R GRM42-6X7R103K200PT K22231802 1- B d1
C 1539 CHIP CAP. 1uF 25V W5R CM32W5R105K25AT K22145801 1-17 A F1
C 1539 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 18- A F1
C 1540 CHIP CAP. 0.001uF 500V W5R GRM42-6W5R102K500PT K22271801 1- B d1
C 1541 CHIP CAP. 0.01uF 200V X7R GRM42-6X7R103K200PT K22231802 1- B d1
C 1542 FILM CAP. 18pF 500V UC232H0180J-T K33279029 1-17 A F2
C 1542 FILM CAP. 27pF 500V UC232H0270J-T K33279023 VERS. A 18- A F2
C 1542 FILM CAP. 18pF 500V UC232H0180J-T K33279029 VERS. D 18- A F2
C 1543 FILM CAP. 6pF 500V UC232H0060D-T K33279045 1-17 A G2
C 1543 FILM CAP. 4pF 500V UC232H0040D-T K33279044 VERS. A 18- A G2
Parts List
PA Unit (Lot. 1-61: Replaced by PA-2 Unit)
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
