Vertex Standard VXR-7000 Service Manual

38 VXR-7000 UHF Service Manual
PA Unit (Lot. 1-61: Replaced by PA-2 Unit)
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
C 1543 FILM CAP. 6pF 500V UC232H0060D-T K33279045 VERS. D 18- A G2
C 1544 FILM CAP. 68pF 500V UC232H0680J-T K33279030 1- A G2
C 1545 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g3
C 1548 FILM CAP. 7pF 500V UC232H0070D-T K33279046 1-18 A G2
C 1548 FILM CAP. 7pF 500V UC232H0070D-T K33279046
VERS. A 19- A G2
C 1548 FILM CAP. 7pF 500V UC232H0070D-T K33279046
VERS. D, Ex. EIA (CE) 19- A G2
C 1548 FILM CAP. 2pF 500V UC232H0020D-T K33279043 VERS. D, EIA (CE) 19- A G2
C 1549 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g3
C 1551 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g3
C 1553 CHIP CAP. 0.5pF 50V CK GRM2164C1HR50CD01D K22170201 1-30 B b2
C 1553 CHIP CAP. 0.5pF 50V CK GRM2164C1HR50CD01D K22170201 VERS. A, Ex. EIA (CE) 31- B b2
C 1553 CHIP CAP. 1pF 50V CK GRM2164C1H1R0CD01D K22170202 VERS. A, EIA (CE) 31- B b2
C 1553 CHIP CAP. 0.5pF 50V CK GRM2164C1HR50CD01D K22170201 VERS. D 31- B b2
C 1554 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B c3
C 1555 FILM CAP. 10pF 500V UC232H0100D-T K33279019 1-18 A H2
C 1555 FILM CAP. 10pF 500V UC232H0100D-T K33279019 VERS. A 19- A H2
C 1555 FILM CAP. 10pF 500V UC232H0100D-T K33279019 VERS. D, Ex. EIA (CE) 19- A H2
C 1555 FILM CAP. 6pF 500V UC232H0060D-T K33279045 VERS. D, EIA (CE) 19- A H2
C 1557 FILM CAP. 10pF 500V UC232H0100D-T K33279019 1-18 A H3
C 1557 FILM CAP. 10pF 500V UC232H0100D-T K33279019 VERS. A 19- A H3
C 1557 FILM CAP. 10pF 500V UC232H0100D-T K33279019 VERS. D, Ex. EIA (CE) 19- A H3
C 1557 FILM CAP. 6pF 500V UC232H0060D-T K33279045 VERS. D, EIA (CE) 19- A H3
C 1558 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B b3
C 1559 CHIP CAP. 0.5pF 50V CK GRM2164C1HR50CD01D K22170201 1-30 B b2
C 1559 CHIP CAP. 0.5pF 50V CK GRM2164C1HR50CD01D K22170201 VERS. A, Ex. EIA (CE) 31- B b2
C 1559 CHIP CAP. 1pF 50V CK GRM2164C1H1R0CD01D K22170202 VERS. A, EIA (CE) 31- B b2
C 1559 CHIP CAP. 0.5pF 50V CK GRM2164C1HR50CD01D K22170201 VERS. D 31- B b2
C 1560 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g3
C 1561 FILM CAP. 4pF 500V UC232H0040D-T K33279044 1-18 A I2
C 1561 FILM CAP. 4pF 500V UC232H0040D-T K33279044 VERS. A 19- A I2
C 1561 FILM CAP. 4pF 500V UC232H0040D-T K33279044 VERS. D, Ex. EIA (CE) 19- A I2
C 1561 FILM CAP. 2pF 500V UC232H0020D-T K33279043 VERS. D, EIA (CE) 19- A I2
C 1562 FILM CAP. 47pF 500V UC232H0470J-T K33279034 1-78 B a2
C 1563 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f3
C 1564 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g3
C 1565 CHIP CAP. 6pF 500V CH GRM31M2C2H6R0DV01L K22271209 1-17 A C2
C 1565 CHIP CAP. 9pF 500V CH GRM42-6CH090D500PT K22271212 VERS. A 18- A C2
C 1565 CHIP CAP. 6pF 500V CH GRM31M2C2H6R0DV01L K22271209 VERS. D 18 A C2
C 1565 CHIP CAP. 6pF 500V CH GRM31M2C2H6R0DV01L K22271209 VERS. D, Ex. EIA (CE) 19- A C2
C 1565 CHIP CAP. 10pF 500V CH GRM42-6CH100D500PT K22271213 VERS. D, EIA (CE) 19- A C2
C 1567 FILM CAP. 10pF 500V UC232H0100D-T K33279019 1-18 A H2
C 1567 FILM CAP. 10pF 500V UC232H0100D-T K33279019 VERS. A 19- A H2
C 1567 FILM CAP. 10pF 500V UC232H0100D-T K33279019 VERS. D, Ex. EIA (CE) 19- A H2
C 1567 FILM CAP. 6pF 500V UC232H0060D-T K33279045 VERS. D, EIA (CE) 19- A H2
C 1571 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1-18 A C3
C 1571 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 VERS. A 19-30 A C3
C 1571 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 VERS. A, Ex. EIA (CE) 31- A C3
C 1571 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 VERS. A, EIA (CE) 31- A C3
C 1571 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 VERS. D, Ex. EIA (CE) 19- A C3
C 1571 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 VERS. D, EIA (CE) 19- A C3
C 1572 CERAMIC CAP. 1pF 500V CK DD05-979CK010C500 K26270102 VERS. A, EIA (CE) 31-
C 1572 CERAMIC CAP. 1pF 500V CK DD05-979CK010C500 K26270102 VERS. D, EIA (CE) 19-
C 1573 CERAMIC CAP. 2pF 500V CK RCC05CK020C-L46AU K02279006 VERS. A, EIA (CE) 31-
C 1573 CERAMIC CAP. 2pF 500V CK DD05-979CK020C500 K26270104 VERS. D, EIA (CE) 19-23
C 1573 CERAMIC CAP. 2pF 500V CK RCC05CK020C-L46AU K02279006 VERS. D, EIA (CE) 24-
D 1501 DIODE RN739F T106 G2070626 1- B i2
D 1502 DIODE MA143-(TX) G2070536 1- B i2
D 1503 DIODE 1SS319(TE85R.F) G2070080 1- B c3
D 1504 DIODE 1SS319(TE85R.F) G2070080 1- B b2
FB1501 M.RFC FBA03VA450AB-00 L1190389 1- A B2
FB1502 M.RFC FBA03VA450AB-00 L1190389 1- A D2
FB1504 CORE 3A4-TMEC-TR16A L9190126 VERS. A, EIA (CE) 31-
FB1504 CORE 3A4-TMEC-TR16A L9190126 VERS. D, EIA (CE) 19-
FB1505 CORE 3A4-TMEC-TR16A L9190126 VERS. A, EIA (CE) 31-
FB1505 CORE 3A4-TMEC-TR16A L9190126 VERS. D, EIA (CE) 19-
FB1506 CORE 3A4-TMEC-TR16A L9190126 VERS. A, EIA (CE) 31-
FB1506 CORE 3A4-TMEC-TR16A L9190126 VERS. D, EIA (CE) 19-
