Vertex Standard VXR-7000 Service Manual

39VXR-7000 UHF Service Manual
PA Unit (Lot. 1-61: Replaced by PA-2 Unit)
Parts List
J 1501 CONNECTOR TMP-J01X-V6 P1090210 1- A A2
JP1501 WIRE ASSY A1367+ T9206790 1- A C3
JP1502 WIRE ASSY A1368 T9206850 1-8
JP1502 WIRE ASSY A1368 T9206850A 9-
JP1503 WIRE ASSY RED 230 FV2/(3) T9318118 1-18
JP1503 WIRE ASSY RED 230 FV2/(3) T9318118 Ex. EIA (CE) 19-
JP1504 WIRE ASSY BLK 240 FV2/(3) T9318119 1-18
JP1504 WIRE ASSY BLK 240 FV2/(3) T9318119 Ex. EIA (CE) 19-
JP1505 WIRE ASSY A1367 T9206959 VERS. A, EIA (CE) 31-
JP1505 WIRE ASSY A1367 T9206959 VERS. D, EIA (CE) 19-
L 1501 M.RFC 0.012uH HK2125 12NJ-T L1690378 1- B i2
L 1502 M.RFC 0.01uH HK2125 10NJ-T L1690377 1- B h2
L 1503 COIL A1 4.5T4.5D0.8UEW R L0021907A 1- A B2
L 1504 COIL A2 0.5T5.0D0.8TA L0022516 1- A D2
L 1505 COIL A1 5.5T4.0D0.6UEW R L0021826A 1- A D2
L 1506 COIL A1 1.5T6.0D1.2ACW R L0022116 1- A F1
L 1507 COIL A1 1.5T5.0D1.2UEW R L0022163 1- A F1
L 1508 COIL A1 1.5T5.0D1.2UEW R L0022163 1- A G2
L 1509 COIL A1 1.5T5.0D1.2UEW R L0022163 1- A H2
L 1510 COIL A1 1.5T5.0D1.2UEW R L0022163 1- A H3
L 1511 COIL A1 1.5T5.0D1.2UEW R L0022163 1- A I2
Q 1501 TRANSISTOR 2SC3357-T2 RF G3333577F 1- B i2
Q 1502 IC PF0341A G1092945 VERS. A 18- A A1
Q 1502 IC PF0342A G1092946 VERS. D 1- A A1
Q 1503 TRANSISTOR 2SB1122S-TD G3211228S 1-78 B h2
Q 1504 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B h2
Q 1505 TRANSISTOR 2SB1122S-TD G3211228S 1-78 B h3
Q 1506 TRANSISTOR UN5213-(TX) G3070192 1- B h3
Q 1507 TRANSISTOR 2SC2905-01 G3329050 25W 19- A E2
Q 1507 TRANSISTOR 2SC3102 G3331020 50W 1- A E2
Q 1508 IC NJM78L09UA-TE2 G1091305 1- B g2
Q 1509 IC TA75S01F(TE85R.F) G1091593 1- B g3
R 1501 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- B i2
R 1502 CHIP RES. 270 1/16W 5% RMC1/16 271JATP J24185271 1- B i2
R 1503 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1- B i2
R 1504 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B i2
R 1505 CHIP RES. 18 1/10W 5% RMC1/10T 180J J24205180 1- B i2
R 1506 CHIP RES. 1.5k 1/16W 5% RMC1/16 152JATP J24185152 1- B i2
R 1507 CHIP RES. 1.5k 1/16W 5% RMC1/16 152JATP J24185152 1- B h2
R 1508 CHIP RES. 8.2 1/10W 5% RMC1/10T 8R2J J24205829 1- A A2
R 1509 CHIP RES. 150 1/10W 5% RMC1/10T 151J J24205151 1- A B2
R 1510 CHIP RES. 8.2 1/10W 5% RMC1/10T 8R2J J24205829 1- A B2
R 1511 CHIP RES. 470 1/10W 5% RMC1/10T 471J J24205471 1- A B2
R 1512 CHIP RES. 820 1/10W 5% RMC1/10T 821J J24205821 1-18 A B2
R 1512 CHIP RES. 820 1/10W 5% RMC1/10T 821J J24205821 VERS. A 19- A B2
R 1512 CHIP RES. 820 1/10W 5% RMC1/10T 821J J24205821 VERS. D, Ex. EIA (CE) 19- A B2
R 1512 CHIP RES. 1k 1/10W 5% RMC1/10T 102J J24205102 VERS. D, EIA (CE) 19- A B2
R 1513 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B h2
R 1514 CHIP RES. 22 1/16W 5% RMC1/16 220JATP J24185220 1- B h2
R 1515 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- B h2
R 1516 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B h3
R 1517 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B h3
R 1520 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B h2
R 1521 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B h3
R 1522 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B g2
R 1523 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B g3
R 1524 CHIP RES. 8.2k 1/10W 5% RMC1/10T 822J J24205822 1-17 B c3
R 1524 CHIP RES. 6.8k 1/10W 5% RMC1/10T 682J J24205682 VERS. A 18- B c3
R 1524 CHIP RES. 8.2k 1/10W 5% RMC1/10T 822J J24205822 VERS. D 18 B c3
R 1524 CHIP RES. 8.2k 1/10W 5% RMC1/10T 822J J24205822 VERS. D, Ex. EIA (CE) 19- B c3
R 1524 CHIP RES. 1.8k 1/10W 5% RMC1/10T 182J J24205182 VERS. D, EIA (CE) 19- B c3
R 1525 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1-17 B c3
R 1525 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 VERS. A 18-30 B c3
R 1525 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 VERS. A, Ex. EIA (CE) 31- B c3
R 1525 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 VERS. A, EIA (CE) 31- B c3
R 1525 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 VERS. D 18 B c3
R 1525 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 VERS. D, Ex. EIA (CE) 19- B c3
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
