40 VXR-7000 UHF Service Manual

R 1525 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183

VERS. D, EIA (CE)

19- B c3

R 1526 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B g3

R 1527 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B g2

R 1528 CHIP RES. 8.2k 1/10W 5% RMC1/10T 822J J24205822 1-17 B b3

R 1528 CHIP RES. 6.8k 1/10W 5% RMC1/10T 682J J24205682

VERS. A

18- B b3

R 1528 CHIP RES. 8.2k 1/10W 5% RMC1/10T 822J J24205822

VERS.D

18 B b3

R 1528 CHIP RES. 8.2k 1/10W 5% RMC1/10T 822J J24205822

VERS. D, Ex. EIA (CE)

19- B b3

R 1528 CHIP RES. 1.8k 1/10W 5% RMC1/10T 182J J24205182

VERS. D, EIA (CE)

19- B b3

R 1529 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153 1-17 B b3

R 1529 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183

VERS. A

18-30 B b3

R 1529 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183

VERS. A, Ex. EIA (CE)

31- B b3

R 1529 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682

VERS. A, EIA (CE)

31- B b3

R 1529 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153

VERS. D

18 B b3

R 1529 CHIP RES. 15k 1/16W 5% RMC1/16 153JATP J24185153

VERS. D, Ex. EIA (CE)

19- B b3

R 1529 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183

VERS. D, EIA (CE)

19- B b3

R 1530 CHIP RES. 47k 1/10W 5% RMC1/10T 473J J24205473 1- B a3

R 1531 CHIP RES. 47k 1/10W 5% RMC1/10T 473J J24205473 1- B a3

R 1532 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- B h2

TH1501 THERMISTOR NT732ATD2.0K K G9090079 1- A D3

SHIELD PLATE (PA) RA0073100 1-

NYLON CLAMP PLT-1M BK-1 S3000022 1-

GROUND PLATE RA0015200 1-

GAP PAD GP1-5.2-015025 S6000379 1-

LEAF SPRING R0140031 1-

LEAF SPRING R0140031

VERS. A, EIA (CE)

31-

LEAF SPRING R0140031

VERS. D, EIA (CE)

19-

LEAF SPRING R0140031

VERS. A, EIA (CE)

31-

LEAF SPRING R0140031

VERS. D, EIA (CE)

19-

SHIELD PLATE R0137780

VERS. A, EIA (CE)

31-

SHIELD PLATE R0137780

VERS. D, EIA (CE)

19-
