45VXR-7000 UHF Service Manual

PCB with Components (w/o Q7007 PA Module & Ground Plate) CS1838001 25W VERSION BS1

CS1838003 25W VERSION D

CS1838005 25W VERSION A

CS1838006 50W VERSION A

CS1838007 50W VERSION D

C 7001 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3

C 7002 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A A2

C 7003 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A B2

C 7004 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 7005 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 7006 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 7007 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B2

C 7008 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A B3

C 7009 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A B2

C 7010 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A C2

C 7011 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A B2

C 7012 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 7013 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 7014 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 7015 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 7016 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3

C 7017 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C2

C 7018 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C2

C 7019 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- A C2

C 7020 CHIP CAP. 1uF 50V B GRM32RB11H105KA01L K22175801 1- A D2

C 7021 CHIP CAP. 0.001uF 630V R GRM31BR32J102KY01L K22281801 1-135 A D2

C 7021 CHIP CAP. 0.001uF 630V UJ GRM31A7U2J102JW31D K22281803 136- A D2

C 7022 CHIP CAP. 100pF 500V CH CF316CH101J500AT K22271267 1- A D2

C 7023 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E2

C 7024 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E2

C 7025 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E2

C 7026 CERAMIC CAP. 0.75pF 500V CK HM60SJCKR75C K02279039

25W VERS. D

71- A E2

C 7027 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A G2

C 7028 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G2

C 7029 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G2

C 7030 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G2

C 7031 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A F2

C 7032 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A F3

C 7033 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F3

C 7034 AL.ELECTRO.CAP. 3300uF 25V RJ3-25V332MJ7# K40149070 1- A G1

C 7035 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G1

C 7036 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G1

C 7037 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A F3

C 7038 CHIP CAP. 100pF 500V CH GRM42-6CH101J500PT K22271237

50W

1-70 A F2

C 7039 FILM CAP. 2pF 500V UC232H0020D-T K33279043

25W VERS. A

79- A G2

C 7039 FILM CAP. 2pF 500V UC232H0020D-T K33279043

25W VERS. D

71- A G2

C 7039 FILM CAP. 1pF 500V UC232H0010D-T K33279036

50W VERS. A

76- A G2

C 7040 FILM CAP. 5pF 500V UC232H0050D-T K33279010 1-70 A G2

C 7040 FILM CAP. 6pF 500V UC232H0060D-T K33279045

25W VERS. A

79- A G2

C 7040 FILM CAP. 5pF 500V UC232H0050D-T K33279010

25W VERS. BS1

71- A G2

C 7040 FILM CAP. 4pF 500V UC232H0040D-T K33279044

25W VERS. D

71- A G2

C 7040 FILM CAP. 5pF 500V UC232H0050D-T K33279010

50W VERS. A

76- A G2

C 7040 FILM CAP. 5pF 500V UC232H0050D-T K33279010

50W VERS. D

71- A G2

C 7041 CHIP CAP. 2pF 200V CH GRM2194C2D2R0CY21D K22230206 1- A G3

C 7042 FILM CAP. 6pF 500V UC232H0060D-T K33279045 1-70 A H2

C 7042 FILM CAP. 7pF 500V UC232H0070D-T K33279046

25W VERS. A

79- A H2

C 7042 FILM CAP. 6pF 500V UC232H0060D-T K33279045

25W VERS. BS1

71- A H2

C 7042 FILM CAP. 5pF 500V UC232H0050D-T K33279010

25W VERS. D

71- A H2

C 7042 FILM CAP. 6pF 500V UC232H0060D-T K33279045

50W VERS. A

76- A H2

C 7042 FILM CAP. 6pF 500V UC232H0060D-T K33279045

50W VERS. D

71- A H2

C 7043 FILM CAP. 2pF 500V UC232H0020D-T K33279043 1-70 A H2

C 7043 FILM CAP. 2pF 500V UC232H0020D-T K33279043

25W VERS. A

79- A H2

C 7043 FILM CAP. 2pF 500V UC232H0020D-T K33279043

25W VERS. BS1

71- A H2

C 7043 FILM CAP. 1pF 500V UC232H0010D-T K33279036

25W VERS. D

71- A H2

C 7043 FILM CAP. 1pF 500V UC232H0010D-T K33279036

50W VERS. A

76- A H2

C 7043 FILM CAP. 2pF 500V UC232H0020D-T K33279043

50W VERS. D

71- A H2

C 7044 CHIP CAP. 100pF 500V CH GRM42-6CH101J500PT K22271237 1- A H2

Parts List

PA-2 Unit (Lot. 62~)

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE

LAYADR
