46 VXR-7000 UHF Service Manual
DESCRIPTION V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
PA-2 Unit (Lot. 62~)
C 7045 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3
C 7046 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D3
C 7047 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3
C 7048 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D3
C 7049 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A D3
C 7051 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3
C 7052 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D3
C 7053 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D3
C 7054 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3
C 7055 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3
C 7056 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D2
C 7057 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A E2
C 7058 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E2
C 7059 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A E3
C 7060 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- A D2
C 7061 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A C3
C 7062 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3
C 7063 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3
C 7064 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3
C 7065 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3
C 7066 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 1- A C3
C 7067 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A A3
C 7068 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D2
C 7069 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D3
C 7070 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3
C 7071 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3
C 7072 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3
C 7073 CHIP CAP. 3pF 200V CJ GRM2193C2D3R0CY21D K22230210 1-189 A G2
C 7073 CHIP CAP. 3pF 250V C0G GQM2195C2E3R0CB12D K22240246 190- A G2
C 7074 CHIP CAP. 1pF 200V CK GRM2194C2D1R0CY21D K22230208 1-188 A H2
C 7074 CHIP CAP. 1pF 200V CH 0805N1R0C201CT K22234216 189- A H2
C 7077 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E2
C 7078 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3
C 7079 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3
C 7080 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D3
C 7081 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3
C 7082 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A F3
C 7083 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F3
C 7084 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1-
D 7001 DIODE RN739F T106 G2070626 1- A A2
D 7002 DIODE BAS316 G2070716 1- A B3
D 7003 DIODE HSM88AS TR-E G2070170 1- A F3
D 7004 DIODE HSM88AS TR-E G2070170 1- A G2
D 7005 DIODE RN739F T106 G2070626 1- A C2
D 7006 DIODE UDZS TE-17 5.6B G2070910 1- A C2
D 7007 DIODE BAS316 G2070716 1- A D3
D 7008 DIODE BAS316 G2070716 1- A D3
D 7009 SURGE ABSORBER RCCA-201Q43UA Q9000755 1-62 A I2
D 7009 SURGE ABSORBER RHCA-201Q43U Q9000825 25W 63-70 A I2
D 7009 SURGE ABSORBER RHCA-201Q43U Q9000825 25W VERS. A 79- A I2
D 7009 SURGE ABSORBER RHCA-201Q43U Q9000825 25W VERS. BS1 71- A I2
D 7009 SURGE ABSORBER RHCA-301Q43U Q9000827 25W VERS. D 71- A I2
D 7009 SURGE ABSORBER RHCA-301Q43U Q9000827 50W 63-70 A I2
D 7009 SURGE ABSORBER RHCA-301Q43U Q9000827 50W VERS. A 76- A I2
D 7009 SURGE ABSORBER RHCA-301Q43U Q9000827 50W VERS. D 71- A I2
FB7001 M.RFC FBA03VA450AB-00 L1190389 1-63 B d2
FB7001 M.RFC FBA03VA450AB-00 L1190389 64-70 B d2
FB7002 M.RFC FBA03VA450AB-00 L1190389 1-63 B d2
FB7002 M.RFC FBA03VA450AB-00 L1190389 64-70 B d2
FB7003 M.RFC FBA03VA450AB-00 L1190389 1-63 B c3
FB7003 M.RFC FBA03VA450AB-00 L1190389 64-70 B c3
FB7004 CORE 3A4-TMEC-TR16A L9190126 1-63
FB7004 CORE 3A4-TMEC-TR16A L9190126 25W 64-
FB7005 CORE 3A4-TMEC-TR16A L9190126 1-63
FB7005 CORE 3A4-TMEC-TR16A L9190126 50W 64-
FB7006 CORE 3A4-TMEC-TR16A L9190126 1-63
FB7006 CORE 3A4-TMEC-TR16A L9190126 25W 64-
