Vertex Standard VXR-7000 Service Manual

47VXR-7000 UHF Service Manual
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
PA-2 Unit (Lot. 62~)
J 7001 CONNECTOR TMP-J01X-V6 P1090210 1- A A2
JP7001 WIRE ASSY A1367+ T9206790 1- A C3
JP7002 WIRE ASSY A1368 T9206850A 1-
JP7003 WIRE ASSY RED 230 FV2/(3) T9318118 50W 63-
JP7004 WIRE ASSY BLK 240 FV2/(3) T9318119
50W 63-
JP7005 WIRE ASSY A1367 T9206959 1-62
JP7005 WIRE ASSY A1367 T9206959 25W 63-
L 7001 M.RFC 0.0056uH HK1608 5N6S-T L1690513 1- A B2
L 7002 CHIP COIL 0.064uH LQW31HN64NJ03L L1690258 1- A B3
L 7003 CHIP COIL 0.023uH LQW31HN23NJ03L L1690252 1- A B2
L 7004 COIL 0.015uH AS0803-15NK L0022536 1-138 A E2
L 7004 COIL 0.015uH TAS0803-15NK L0023103 139- A E2
L 7005 COIL 0.01uH AS1003-10NK L0022544 1-138 A G2
L 7005 COIL 0.01uH TAS1003-10NK L0023107 139- A G2
L 7006 COIL 0.015uH AS1203-15NK L0022543 1-70 A G3
L 7006 COIL 0.015uH AS1203-15NK L0022543 25W VERS. A 79-135 AG3
L 7006 COIL 0.015uH TAS1203-15NK L0023106 25W VERS. A 136- A G3
L 7006 COIL 0.015uH AS1203-15NK L0022543 25W VERS. BS1 71-135 AG3
L 7006 COIL 0.015uH TAS1203-15NK L0023106 25W VERS. BS1 136- A G3
L 7006 COIL B2 2.0T4.5D1.2UEW R L0022957 25W VERS. D 71- A G3
L 7006 COIL 0.015uH AS1203-15NK L0022543 50W VERS. A 76-135 AG3
L 7006 COIL 0.015uH TAS1203-15NK L0023106 50W VERS. A 136- A G3
L 7006 COIL 0.015uH AS1203-15NK L0022543 50W VERS. D 71-135 AG3
L 7006 COIL 0.015uH TAS1203-15NK L0023106 50W VERS. D 136- A G3
L 7007 COIL 0.015uH AS1203-15NK L0022543 1-135 A H2
L 7007 COIL 0.015uH TAS1203-15NK L0023106 136- A H2
L 7008 M.RFC 0.018uH ELJ-RE18NJF2 L1690717 1-
L 7009 M.RFC 0.018uH ELJ-RE18NJF2 L1690717 1-
L 7010 COIL A1 0.5T6.0D1.2 ACW L0022115 25W 1-70
L 7010 COIL A2 0.5T5.0D1.2ACW L0022168 25W VERS. A 79-
L 7010 COIL A1 0.5T6.0D1.2 ACW L0022115 25W VERS. BS1 71-
L 7010 COIL A1 0.5T6.0D1.2 ACW L0022115 50W VERS. A 76-
Q 7001 TRANSISTOR 2SC5415E-TD-E G3354158E 1-185 A B2
Q 7001 TRANSISTOR 2SC5415AE-TD-E G3070426 186- A B2
Q 7004 TRANSISTOR FMG2 T148 G3070015 1- A C3
Q 7005 TRANSISTOR 2SA1179N6-CPA-TB G3111797F 1- A C3
Q 7006 TRANSISTOR DTC144EUA T106 G3070041 1- A C3
Q 7007 IC S-AU83L(VX1) G1094135 25W 1-70 A C1
Q 7007 IC S-AU83L(VX1) G1094135 25W VERS. A 79-111 AC1
Q 7007 IC S-AU83AL(VX.Q) G1094427 25W VERS. A 112- A C1
Q 7007 IC S-AU83L(VX1) G1094135 25W VERS. BS1 71-111 AC1
Q 7007 IC S-AU83AL(VX.Q) G1094427 25W VERS. BS1 112- A C1
Q 7007 IC RA30H4452M-122 G1093885 25W VERS. D 71- A C1
Q 7007 IC S-AU93 G1094203 50W 63-70 A C1
Q 7007 IC S-AU82L G1093918 50W VERS. A 76-112 AC1
Q 7007 IC S-AU82AL(VX.Q) G1094680 50W VERS. A 113-156 AC1
Q 7007 IC RA60H4047M1-101 G1094556 50W VERS. A 157- A C1
Q 7007 IC S-AU93 G1094203 50W VERS. D 71-102 AC1
Q 7007 IC S-AU93A(VX.Q) G1094616 50W VERS. D 103-158 AC1
Q 7007 IC RA60H4452M1 G1094520 50W VERS. D 159- A C1
Q 7008 IC NJM78L09UA-TE2 G1091305 1- A D2
Q 7009 IC LM2904PWR G1094010 1- A D3
R 7001 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A A2
R 7002 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A A2
R 7003 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 7004 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A B2
R 7005 CHIP RES. 10 1/4W 5% RMC1/4 100JATP J24245100 1- A B3
R 7006 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- A B3
R 7007 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B3
R 7009 CHIP RES. 4.7 1/4W 5% RMC1/4 4R7JATP J24245479 1- A B3
R 7013 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C3
R 7014 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A C2
R 7015 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A C2
R 7016 CHIP RES. 5.6 1/16W 5% RMC1/16 5R6JATP J24185569 1- A C2
R 7017 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A C2
R 7018 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1-158 A C2
R 7019 CHIP RES. 120 1/10W 5% RMC1/10T 121J J24205121 1-70 A F2
