48 VXR-7000 UHF Service Manual
Parts List
PA-2 Unit (Lot. 62~)
R 7019 CHIP RES. 100 1/10W 5% RMC1/10T 101J J24205101 25W 71- A F2
R 7019 CHIP RES. 120 1/10W 5% RMC1/10T 121J J24205121
50W 71 A F2
R 7019 CHIP RES. 100 1/10W 5% RMC1/10T 101J J24205101
50W 72- A F2
R 7020 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A G2
R 7021 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A G2
R 7022 CHIP RES. 100 1/10W 5% RMC1/10T 101J J24205101 1- A G2
R 7023 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A F3
R 7024 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E3
R 7025 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1-62 A E2
R 7025 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 25W 63-70 A E2
R 7025 CHIP RES. 1.2k 1/16W 5% RMC1/16 122JATP J24185122 25W 71- A E2
R 7025 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 50W 63- A E2
R 7026 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A H2
R 7027 CHIP RES. 220k 1/10W 5% RMC1/10T 224J J24205224 1- A D3
R 7028 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A D3
R 7029 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A D3
R 7030 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A D3
R 7031 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D3
R 7032 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A D3
R 7033 CHIP RES. 1k 1/10W 5% RMC1/10T 102J J24205102 1- A D3
R 7034 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1- A D3
R 7035 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C3
R 7036 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A C3
R 7038 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A D2
R 7039 CHIP RES. 0 1/10W 5% RMC1/10T 000J J24205000 1- A D2
R 7040 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 25W 71-
R 7040 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 50W 63-
R 7041 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 25W 71-
R 7041 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 50W 63-
R 7042 CHIP RES. 0 1/4W 5% RMC1/4 000JATP J24245000 25W VERS. D 71-
R 7042 CHIP RES. 0 1/4W 5% RMC1/4 000JATP J24245000 50W VERS. D 71-
TH7001 THERMISTOR NT732ATD2.0K K G9090079 1- A D2
TH7002 THERMISTOR 157-502-53002TP G9090049 1- A E2
NYLON CLAMP PLT-1M BK-1 S3000022 1-
NYLON CLAMP PLT-1M BK-1 S3000022 1-
HEATSINK PLATE RA0651100 1-
HEATSINK PLATE RA0651100 63-70
BINDING HEAD SCREW M3X6 U20306001 1-
BINDING HEAD SCREW M3X4 U20304001 71-
SHIELD CASE RA0689900 62
SHIELD CASE RA0689900 63-
SHIELD CASE RA0689900 71-
NYLON CLAMP PLT-1M BK-1 S3000022 1-63
NYLON CLAMP PLT-1M BK-1 S3000022 25W 64-
NYLON CLAMP PLT-1M BK-1 S3000022 1-63
NYLON CLAMP PLT-1M BK-1 S3000022 25W 64-
NYLON CLAMP PLT-1M BK-1 S3000022 1-63
NYLON CLAMP PLT-1M BK-1 S3000022 25W 64-
GROUND PLATE RA069650A 25W VERS. A 71-
GROUND PLATE RA069650A 25W VERS. D 71-
GROUND PLATE RA069650A 25W VERS. BS1 71-
GROUND PLATE RA069650A 50W VERS. D 71-158
TERMINAL B4 AG M3 Q6000114 50W VERS. A 157-
TERMINAL B4 AG M3 Q6000114 50W VERS. D 159-
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
