53VXR-7000 UHF Service Manual

PCB with Components Not Supply

C 2001 CHIP CAP. 0.033uF 16V B ECJ1VB1C333K K22129515 1-21 A C2

C 2001 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 22- A C2

C 2002 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B a3

C 2003 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A C3

C 2004 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A C2

C 2005 CHIP TA.CAP. 1.5uF 16V TEESVA1C155M8R K78120020 1- B b2

C 2006 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A C2

C 2007 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b2

C 2009 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C3

C 2010 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A C2

C 2011 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A C2

C 2012 CHIP CAP. 5pF 50V UJ GRM1883U1H5R0CZ01D K22174305 1- A C2

C 2013 CHIP TA.CAP. 0.1uF 35V TEESVA1V104M8R K78160025 1- B b2

C 2015 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B b1

C 2016 CHIP CAP. 82pF 50V UJ GRM1883U1H820JZ01D K22174330 1- A C2

C 2017 CHIP CAP. 15pF 50V UJ GRM1883U1H150JZ01D K22174312 1- A C2

C 2018 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A C3

C 2019 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C2

C 2020 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1-17 A B2

C 2020 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206

VERS. A

22- A B2

C 2020 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235

VERS. D

18- A B2

C 2021 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C3

C 2022 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203

VERS. A

18-21 A A2

C 2023 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B a2

C 2024 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B a2

C 2025 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1-17 A B2

C 2025 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209

VERS. A

18-21 A B2

C 2025 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215

VERS. A

22- A B2

C 2025 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211

VERS. D

18- A B2

C 2026 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C2

C 2027 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a1

C 2028 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. A

18-21 A B2

C 2029 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 2030 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1-26 A B2

C 2030 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209

VERS. A

27- A B2

C 2030 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208

VERS. D

27- A B2

C 2031 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B a1

C 2032 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1-17 A B2

C 2032 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207

VERS. A

18- A B2

C 2032 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206

VERS. D

18- A B2

C 2033 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a3

C 2034 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a3

C 2035 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1-17 A B2

C 2035 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202

VERS. A

18-21 A B2

C 2035 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201

VERS. A

22- A B2

C 2035 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201

VERS. D

18- A B2

C 2036 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A B2

C 2037 CHIP CAP. 0.047uF 25V F GRM39F473Z25PT K22145002 1- A B2

C 2038 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a2

C 2039 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 2040 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B2

C 2041 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A B2

C 2042 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 2043 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A B2

C 2044 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B b2

C 2045 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A B3

C 2046 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B b2

C 2047 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b2

C 2048 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A B3

C 2049 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B a1

C 2050 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 2051 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B a1

C 2052 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3

C 2053 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 2054 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B b1

C 2055 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A B3

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT. SIDE

LAYADR

TX Unit (Lot.1-59: Replaced by TX-2 Unit)

Parts List

REF.
