54 VXR-7000 UHF Service Manual
TX Unit (Lot.1-59: Replaced by TX-2 Unit)
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE
LAYADR
Parts List
C 2056 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A A1
C 2057 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1-3 B b1
C 2057 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 4- B b1
C 2058 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- B c3
C 2059 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A A1
C 2060 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A3
C 2061 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- B c3
C 2062 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1-3 B b1
C 2062 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 4- B b1
C 2063 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A B1
C 2064 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1-3 B b1
C 2064 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 4- B b1
C 2065 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B c1
C 2066 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A3
C 2067 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1-3 B b1
C 2067 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 4- B b1
C 2068 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1-3 B b1
C 2068 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 4- B b1
C 2069 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1-3 B b1
C 2069 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 4- B b1
C 2070 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A A3
C 2071 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B3
C 2072 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1- A C2
C 2074 CHIP CAP. 0.0047uF 50V B GRM188B11H472KA01D K22174817 1- A B1
C 2075 CHIP CAP. 0.033uF 16V B ECJ1VB1C333K K22129515 1- A B1
C 2076 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A C1
C 2080 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a1
C 2081 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C1
C 2082 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A B3
D 2001 DIODE RD6.8UMB2-T1B G2070438 1- B a3
D 2002 DIODE HVU350 TRF-E G2070380 1- A A2
D 2003 DIODE HVU350 TRF-E G2070380 1- A A1
D 2004 DIODE HVU350 TRF-E G2070380 1- A C2
D 2005 DIODE HVU350 TRF-E G2070380 1- A B2
D 2006 DIODE HVU350 TRF-E G2070380 1- A B1
D 2007 DIODE HVU350 TRF-E G2070380 1- A C2
D 2008 DIODE HVU350 TRF-E G2070380 1- A B2
D 2009 DIODE RN739F T106 G2070626 1- A B3
D 2010 DIODE RN739F T106 G2070626 1- A A3
D 2011 DIODE MA143-(TX) G2070536 1- B a3
D 2012 DIODE MA143-(TX) G2070536 1- B a3
J 2001 CONNECTOR TMP-J01X-A2 P1090255 1- A A3
JP2001 WIRE ASSY A1367+ T9206792 1- A C1
L 2001 M.RFC 0.082uH HK1608 82NJ-T L1690527 1-21 A B1
L 2001 M.RFC 0.12uH HK1608 R12J-T L1690937
VERS. A
22- A B1
L 2001 M.RFC 0.082uH HK1608 82NJ-T L1690527
VERS. D
22- A B1
L 2002 M.RFC 0.082uH HK1608 82NJ-T L1690527 1-21 A B2
L 2002 M.RFC 0.12uH HK1608 R12J-T L1690937
VERS. A
22- A B2
L 2002 M.RFC 0.082uH HK1608 82NJ-T L1690527
VERS. D
22- A B2
L 2003 COIL E2 0.5-2.0-5T-R L0022487 1-17 A B2
L 2003 COIL E2 0.5-2.0-6T-R L0022488
VERS. A
18- A B2
L 2003 COIL E2 0.5-2.0-5T-R L0022487
VERS. D
18- A B2
L 2004 M.RFC 0.082uH HK1608 82NJ-T L1690527 1-17 A B2
L 2004 M.RFC 0.12uH HK1608 R12J-T L1690937
VERS. A
18- A B2
L 2004 M.RFC 0.082uH HK1608 82NJ-T L1690527
VERS. D
18- A B2
L 2005 M.RFC 0.082uH HK1608 82NJ-T L1690527 1- A B2
L 2006 CHIP COIL 0.022uH C2520C-22NK L1690536 1- A B2
L 2007 M.RFC 0.022uH HK1608 22NJ-T L1690520 1- A B3
Q 2001 IC
MB15A02PFV1-G-BND-EFE1
G1092541 1- A C3
Q 2002 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A C2
Q 2003 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- A C3
Q 2004 TRANSISTOR UN5215-(TX) G3070193 1- A C3
Q 2005 FET 2SK508-T2B K52 A G3805087B 1- A B2
Q 2006 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B a3
Q 2007 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- B a3
Q 2008 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- A B2
Q 2009 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B b2
