Vertex Standard VXR-7000 Service Manual

55VXR-7000 UHF Service Manual
TX Unit (Lot.1-59: Replaced by TX-2 Unit)
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
Q 2010 TRANSISTOR 2SC3357-T2 RF G3333577F 1- A B3
Q 2011 TRANSISTOR XN1213-(TX) G3070194 1- B c3
Q 2012 IC NJM78L05UA-TE1 G1091325 1- A A1
Q 2013 TRANSISTOR 2SA1179N6-CPA-TB G3111797F 1- B c1
Q 2014 TRANSISTOR UN5213-(TX) G3070192 1- B c1
Q 2015 TRANSISTOR UN5213-(TX) G3070192 1- B c1
Q 2016 TRANSISTOR 2SA1179N6-CPA-TB G3111797F 1- B c1
Q 2019 TRANSISTOR XN1213-(TX) G3070194 1- B c2
Q 2020 IC NJM2904M-TE2 G1093091 1- B a1
Q 2021 TRANSISTOR 2SD1664 T100 Q G3416647Q 1- B a2
Q 2022 TRANSISTOR 2SD1664 T100 Q G3416647Q 1- B a2
R 2002 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B a3
R 2003 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B a3
R 2004 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1-21 B b2
R 2004 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 VERS. A 22- B b2
R 2004 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 VERS. D 22- B b2
R 2005 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C2
R 2006 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- B b2
R 2007 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A C2
R 2008 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A C3
R 2009 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A C2
R 2010 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A C2
R 2011 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A C2
R 2012 CHIP RES. 33 1/16W 5% RMC1/16 330JATP J24185330 1- A B2
R 2014 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A C3
R 2015 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A C2
R 2016 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C3
R 2017 CHIP RES. 220k 1/16W 1% RMC1/16 224FTP J24183224 1- A C2
R 2018 CHIP RES. 220k 1/16W 1% RMC1/16 224FTP J24183224 1- A C2
R 2019 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A C2
R 2020 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b1
R 2021 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A C3
R 2022 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A B2
R 2023 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B a3
R 2024 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B a3
R 2025 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A B2
R 2026 CHIP RES. 100k 1/16W 1% RMC1/16 104FTP J24183104 1- B a3
R 2027 CHIP RES. 12k 1/16W 1% RMC1/16 123FTP J24183123 1- B a3
R 2028 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1-26 A B2
R 2028 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 VERS. A 27- A B2
R 2028 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 VERS. D 27- A B2
R 2029 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1-26 A B2
R 2029 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 VERS. A 27- A B2
R 2029 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 VERS. D 27- A B2
R 2030 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- A B2
R 2031 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A B2
R 2032 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B2
R 2033 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A B2
R 2034 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A B2
R 2035 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A B3
R 2036 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- B b3
R 2037 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- B b3
R 2038 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B b2
R 2039 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B3
R 2040 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B3
R 2041 CHIP RES. 47 1/10W 5% RMC1/10T 470J J24205470 1- A B3
R 2043 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A B3
R 2044 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B b1
R 2046 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b1
R 2047 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1-21 A B1
R 2047 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 VERS. A 22- A B1
R 2047 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 VERS. D 22- A B1
R 2048 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A B3
R 2050 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A B3
R 2051 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b2
R 2052 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B1
R 2053 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A B3
