Vertex Standard VXR-7000 Service Manual

56 VXR-7000 UHF Service Manual
R 2054 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A B3
R 2055 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C3
R 2056 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A A3
R 2057 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c1
R 2058 CHIP RES. 820 1/16W 5% RMC1/16 821JATP J24185821 1- A A3
R 2059 CHIP RES. 680 1/16W 1% RMC1/16 681FTP J24183681 1- A C3
R 2060 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B a3
R 2061 CHIP RES. 6.8k 1/16W 1% RMC1/16 682FTP J24183682 1- A C3
R 2062 CHIP RES. 8.2k 1/16W 1% RMC1/16 822FTP J24183822 1- B a3
R 2063 CHIP RES. 15k 1/16W 1% RMC1/16 153FTP J24183153 1- B a3
R 2064 CHIP RES. 10k 1/16W 1% RMC1/16 103FTP J24183103 1- B a3
R 2065 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B a3
R 2067 CHIP RES. 4.7k 1/16W 1% RMC1/16 472FTP J24183472 1- B a3
R 2068 CHIP RES. 2.2k 1/16W 1% RMC1/16 222FTP J24183222 1- B a3
R 2069 CHIP RES. 4.7k 1/16W 1% RMC1/16 472FTP J24183472 1- B a3
R 2070 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c1
R 2071 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c1
R 2078 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c2
R 2079 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- B c3
R 2080 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B c3
R 2081 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B c3
R 2082 CHIP RES. 1.5k 1/16W 5% RMC1/16 152JATP J24185152 1- A C1
R 2083 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C1
R 2084 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 1- A C1
R 2085 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 1- A C1
R 2086 CHIP RES. 470k 1/16W 5% RMC1/16 474JATP J24185474 1- A C1
R 2087 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A C1
R 2088 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A C1
R 2089 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- B a1
R 2090 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- B a1
R 2093 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C1
R 2094 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A C1
R 2095 CHIP RES. 220 1W 5% RMC1 221JTE J24305221 1- B a2
R 2096 CHIP RES. 220 1W 5% RMC1 221JTE J24305221 1- B a2
R 2097 CHIP RES. 82 1W 5% RMC1 820JTE J24305820 1- B a2
R 2099 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C1
R 2100 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A C1
R 2101 CHIP RES. 12k 1/16W 1% RMC1/16 123FTP J24183123 1- B a3
R 2102 CHIP RES. 1.5k 1/16W 1% RMC1/16 152FTP J24183152 1- B a3
R 2103 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C1
TC2001 TRIMMER CAP. 10pF ECR-JA010A11X K91000227 1- A C2
TH2001 THERMISTOR NTCG203SH223JT G9090106 1- B a3
TH2002 THERMISTOR NTCG203NH153JT G9090105 1- B a3
TH2003 THERMISTOR NT732ATD2.0K K G9090079 1- B c3
X 2001 XTAL TOP-B 14.4MHz 14.4MHZ H0103221 1- A C2
SHIELD CASE RA0014300 1-
SHIELD CASE VCO R0151950 1-
LEAF SPRING R0140031 4-
LEAF SPRING R0140031 VERS. A, EIA (CE) 31-
GROUND PLATE RA0338600 VERS. A, EIA (CE) 31-
TX Unit (Lot.1-59: Replaced by TX-2 Unit)
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
