73VXR-7000 UHF Service Manual

RX Unit (Lot.1-59: Replaced by RX-2 Unit)

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE

LAYADR

Parts List

C 3111 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E3

C 3112 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c3

C 3114 CHIP CAP. 180pF 50V CH GRM1882C1H181JA01D K22174241 1- B b2

C 3115 CHIP CAP. 180pF 50V CH GRM1882C1H181JA01D K22174241 1- B b2

C 3116 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b3

C 3117 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B a2

C 3118 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A C3

C 3118 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 26- A C3

C 3119 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B c3

C 3120 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 3121 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E2

C 3122 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B b3

C 3123 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b3

C 3124 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b3

C 3125 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A D3

C 3126 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 3127 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b2

C 3128 CHIP CAP. 0.0047uF 50V B GRM188B11H472KA01D K22174817 1- B b2

C 3129 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d3

C 3130 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A D3

C 3132 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 3133 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D2

C 3134 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A D2

C 3135 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E2

C 3136 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 3137 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 3138 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A D3

C 3140 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A C3

C 3141 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E2

C 3142 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E2

C 3143 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 3144 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- A E2

C 3145 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 3146 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B d3

C 3147 CHIP CAP. 18pF 50V UJ GRM1883U1H180JZ01D K22174314 1- A A2

C 3149 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B c3

C 3154 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D1

C 3155 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201

VERS. A

18-23 A D1

C 3157 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A D2

C 3157 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207

VERS. A

18- A D2

C 3157 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211

VERS. D

18- A D2

C 3158 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A D2

C 3158 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207

VERS. A

18- A D2

C 3158 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211

VERS. D

18- A D2

C 3159 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D2

C 3164 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c2

C 3165 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b2

C 3168 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A E1

C 3172 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A E2

C 3174 CHIP CAP. 18pF 50V RH GRM1882R1H180JZ01D K22174515 1- A A2

CD3001 CERAMIC DISC CDBLA455KCAY07-B0 H7900180 1- A D2

CF3001 CERAMIC FILTER CFWLB455KGFA-B0 H3900399 1- A E3

CF3002 CERAMIC FILTER CFWLB455KFFA-B0 H3900395 1- A F3

D 3001 DIODE 1SS302(TE85R.F) G2070088 1- B a1

D 3002 DIODE RD6.8UMB2-T1B G2070438 1- B f2

D 3003 DIODE RN739F T106 G2070626 1- A F1

D 3004 DIODE HVU350 TRF-E G2070380 1- A E2

D 3005 DIODE HVU350 TRF-E G2070380 1- A B3

D 3006 DIODE HVU350 TRF-E G2070380 1- A B3

D 3007 DIODE HVU350 TRF-E G2070380 1- A E2

D 3008 DIODE HVU350 TRF-E G2070380 1- A B3

D 3009 DIODE HVU350 TRF-E G2070380 1- A B3

D 3010 DIODE HVU350 TRF-E G2070380 1- A A2

D 3011 IC GN2011-Q(TX) G1092183 1- A C2

D 3012 DIODE MA142WK-(TX) G2070534 1- B b3

D 3013 DIODE MA142WK-(TX) G2070534 1- B b3

D 3014 DIODE HZM5.6NB2 TR-E G2070722 1- B c3
