Vertex Standard VXR-7000 Service Manual

74 VXR-7000 UHF Service Manual
RX Unit (Lot.1-59: Replaced by RX-2 Unit)
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
D 3015 DIODE MA143-(TX) G2070536 1- A E2
D 3016 DIODE MA143-(TX) G2070536 1- A E2
D 3017 DIODE MA143-(TX) G2070536 1- B f1
D 3018 DIODE MA143-(TX) G2070536 1- B f2
D 3019 DIODE HVU350 TRF-E G2070380 1- A D2
D 3020 DIODE HVU350 TRF-E G2070380 1- A D2
J 3001 CONNECTOR TMP-J01X-V6 P1090210 1- A C1
JP3001 WIRE ASSY A1367+ T9206791 1- A A3
JP3002 WIRE ASSY A1367+ T9206788 1- A F1
JP3003 WIRE ASSY GRN 35 2/2 T50503500 10- A A2
L 3001 M.RFC 3.3uH LK1608 3R3K-T L1690686 1- A F1
L 3002 COIL E2 0.35-1.6-4T-L L0022456 1- A E1
L 3002 COIL E2 0.35-1.6-5.5T-L L0022616 VERS. A 18 A E1
L 3002 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 19- A E1
L 3002 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 18- A E1
L 3003 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A B3
L 3004 COIL E2 0.35-1.6-4T-L L0022456 1- A E1
L 3004 COIL E2 0.35-1.6-5.5T-L L0022616 VERS. A 18 A E1
L 3004 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 19- A E1
L 3004 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 18- A E1
L 3005 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A B3
L 3006 M.RFC 0.015uH LL1608-F15NK L1690361 1- A E1
L 3007 COIL E2 0.5-2.0-6T-R L0022488 1- A B3
L 3007 COIL E2 0.5-2.0-7T-R L0022489 VERS. A 18- A B3
L 3007 COIL E2 0.5-2.0-6T-R L0022488 VERS. D 18- A B3
L 3008 CHIP COIL 0.017uH LQW31HN17NJ03L L1690249 1- A E1
L 3009 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A B2
L 3010 COIL E2 0.35-1.6-4T-L L0022456 1- A D1
L 3010 COIL E2 0.35-1.6-5.5T-L L0022616 VERS. A 18 A D1
L 3010 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 19- A D1
L 3010 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 18- A D1
L 3011 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A C2
L 3012 COIL E2 0.35-1.6-4T-L L0022456 1- A D1
L 3012 COIL E2 0.35-1.6-5.5T-L L0022616 VERS. A 18 A D1
L 3012 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 19- A D1
L 3012 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 18- A D1
L 3013 CHIP COIL 0.082uH C2520C-82NK L1690543 1- A B2
L 3014 COIL E2 0.35-1.6-4T-L L0022456 1- A D1
L 3014 COIL E2 0.35-1.6-5.5T-L L0022616 VERS. A 18 A D1
L 3014 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 19- A D1
L 3014 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 18- A D1
L 3015 CHIP COIL 0.022uH C2520C-22NK L1690536 1- A B2
L 3016 COIL E2 0.35-1.6-4T-L L0022456 1- A D1
L 3016 COIL E2 0.35-1.6-5.5T-L L0022616 VERS. A 18 A D1
L 3016 COIL E2 0.35-1.6-4.5T-L L0022577 VERS. A 19- A D1
L 3016 COIL E2 0.35-1.6-4T-L L0022456 VERS. D 18- A D1
L 3018 M.RFC 0.022uH HK2125 22NJ-T L1690381 1- A C1
L 3019 M.RFC 0.022uH HK2125 22NJ-T L1690381 1- A C1
L 3021 M.RFC 0.33uH LK2125 R33K-T L1690313 1- A E3
L 3022 M.RFC 10uH LK2125 100K-T L1690331 1- B d3
L 3023 CHIP COIL 0.68uH C2520C-R68J L1690554 1- A C3
L 3024 M.RFC 0.1uH LK2125 R10K-T L1690307 1- A D3
L 3025 CHIP COIL 1uH C2520F-1R0K L1690584 1- A D3
L 3026 CHIP COIL 0.68uH C2520C-R68J L1690554 1- A D3
Q 3001 IC MB15A02PFV1-G-BND-EFE1 G1092541 1- A A2
Q 3002 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A A2
Q 3003 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- A A1
Q 3004 TRANSISTOR UN5215-(TX) G3070193 1- A A1
Q 3005 TRANSISTOR 2SC3357-T2 RF G3333577F 1- A E1
Q 3006 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B f1
Q 3007 TRANSISTOR 2SA1586Y(TE85R.F) G3115867Y 1- B f1
Q 3008 FET 2SK508-T2B K52 A G3805087B 1- A C2
Q 3009 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- A B2
Q 3010 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- B e2
Q 3011 TRANSISTOR 2SC3357-T2 RF G3333577F 1- A B1
Q 3012 IC TA31136FNG(EL) G1091605 1- A E3
Q 3013 TRANSISTOR 2SC2812L6-TA G3328127F 1- B c2
