Vertex Standard VXR-7000 Service Manual

75VXR-7000 UHF Service Manual
RX Unit (Lot.1-59: Replaced by RX-2 Unit)
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
Parts List
Q 3013 TRANSISTOR 2SC2812N6-CPA-TB-E G3328128F 7- B c2
Q 3014 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- A D3
Q 3015 TRANSISTOR 2SC4116GR(TE85R.F) G3341167G 1- A E2
Q 3016 TRANSISTOR XN1213-(TX) G3070194 1- B a3
Q 3018 TRANSISTOR 2SB1122S-TD G3211228S 1- B c2
Q 3020 TRANSISTOR XN1213-(TX) G3070194 1- B b3
Q 3021 IC NJM78L05UA-TE1 G1091325 1- A C3
Q 3022 TRANSISTOR XN1213-(TX) G3070194 1- B b2
R 3001 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B a1
R 3003 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B e1
R 3004 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B a2
R 3005 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B e2
R 3006 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- B e2
R 3007 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A2
R 3008 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B e2
R 3009 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A E1
R 3010 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A A2
R 3011 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A A1
R 3012 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A A2
R 3013 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A A2
R 3014 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A2
R 3015 CHIP RES. 33 1/16W 5% RMC1/16 330JATP J24185330 1- A B2
R 3016 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A A1
R 3017 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A E2
R 3018 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A A1
R 3019 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A A2
R 3020 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A A1
R 3022 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 3023 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A E1
R 3024 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A E1
R 3025 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A D1
R 3026 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A B2
R 3027 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A E2
R 3028 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A E1
R 3029 CHIP RES. 120k 1/16W 1% RMC1/16 124FTP J24183124 1- B f1
R 3030 CHIP RES. 12k 1/16W 1% RMC1/16 123FTP J24183123 1- B f1
R 3031 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A C2
R 3033 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A B2
R 3034 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B2
R 3035 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- A B2
R 3036 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A B2
R 3037 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- A B2
R 3038 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- B e1
R 3039 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- B e2
R 3041 CHIP RES. 18 1/16W 5% RMC1/16 180JATP J24185180 1- B e1
R 3042 CHIP RES. 56 1/16W 5% RMC1/16 560JATP J24185560 1- B d1
R 3043 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B1
R 3044 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A B1
R 3045 CHIP RES. 150 1/16W 5% RMC1/16 151JATP J24185151 1- A B1
R 3047 CHIP RES. 100 1/10W 5% RMC1/10T 101J J24205101 1- A B1
R 3048 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1 B c2
R 3048 CHIP RES. 100 1/16W 1% RMC1/16 101FTP J24183101 2- B c2
R 3049 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1 B c2
R 3049 CHIP RES. 100 1/16W 1% RMC1/16 101FTP J24183101 2- B c2
R 3050 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B b3
R 3051 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- A E3
R 3053 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B a3
R 3054 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B a3
R 3056 CHIP RES. 1.2k 1/16W 5% RMC1/16 122JATP J24185122 1- A D2
R 3057 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B b3
R 3058 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- B a3
R 3059 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A C3
R 3061 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- B b3
R 3062 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B a2
R 3063 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- B b2
R 3064 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- B b3
R 3065 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c2
