Vertex Standard VXR-7000 Service Manual

76 VXR-7000 UHF Service Manual
R 3066 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B b3
R 3067 CHIP RES. 1.8k 1/16W 5% RMC1/16 182JATP J24185182 1- B b2
R 3068 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B a2
R 3069 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A D3
R 3071 CHIP RES. 47 1/16W 5% RMC1/16 470JATP J24185470 1- A E2
R 3072 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- A E2
R 3074 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
R 3075 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A E2
R 3076 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A E2
R 3077 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B c3
R 3078 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- A D2
R 3079 CHIP RES. 6.8k 1/16W 5% RMC1/16 682JATP J24185682 1- B c3
R 3080 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- A E2
R 3081 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A E2
R 3082 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B a2
R 3083 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b2
R 3084 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b2
R 3086 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A E2
R 3087 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A D3
R 3088 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B b2
R 3089 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c3
R 3090 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B f2
R 3091 CHIP RES. 680 1/16W 1% RMC1/16 681FTP J24183681 1- A A2
R 3092 CHIP RES. 6.8k 1/16W 1% RMC1/16 682FTP J24183682 1- A A2
R 3093 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e1
R 3094 CHIP RES. 27k 1/16W 1% RMC1/16 273FTP J24183273 1- B e1
R 3095 CHIP RES. 47k 1/16W 1% RMC1/16 473FTP J24183473 1- B f1
R 3096 CHIP RES. 82k 1/16W 1% RMC1/16 823FTP J24183823 1- B f1
R 3097 CHIP RES. 56k 1/16W 1% RMC1/16 563FTP J24183563 1- B f1
R 3098 CHIP RES. 3.9k 1/16W 1% RMC1/16 392FTP J24183392 1- B f1
R 3099 CHIP RES. 1k 1/16W 1% RMC1/16 102FTP J24183102 1- B f1
R 3100 CHIP RES. 1.8k 1/16W 1% RMC1/16 182FTP J24183182 1- B f1
R 3105 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D2
R 3106 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A D2
R 3107 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1-
R 3108 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- A B1
R 3109 CHIP RES. 5.6k 1/16W 5% RMC1/16 562JATP J24185562 1- A B1
T 3001 COIL WIDE-TRANS. 3-317611 L0022478 1- A C2
T 3002 COIL WIDE-TRANS. 050812563 92H5 L0022479 1- A C2
T 3003 COIL WIDE-TRANS. 3-317611 L0022478 1- A C2
TC3001 TRIMMER CAP. 10pF ECR-JA010A11X K91000227 1- A A2
TH3001 THERMISTOR NTCG203SH223JT G9090106 1- B f1
TH3002 THERMISTOR NTCG203NH153JT G9090105 1- B f1
X 3001 XTAL TOP-B 14.4MHz 14.4MHZ H0103221 1- A A2
X 3002 XTAL TOP-B 72.895MHz 72.895MHZ H0103161A 1- A E3
XF3001 XTAL FILTER 73S10A H1102297 1- A C3
XF3002 XTAL FILTER 73S10A H1102297 1- A D3
SHIELD CASE CASE-S7GDH L9190016 1-
SHIELD CASE CASE-S7GDH L9190016 1-
SHIELD CASE CASE-S7GDH L9190016 VERS. A, EIA (CE) 31-
SHIELD CASE RA0014300 1-
SHIELD CASE VCO R0151950 1-
SHIELD CASE RA0014200 1-
NYLON CLAMP PLT-1M BK-1 S3000022 1-
LEAF SPRING R0140031 4-
LEAF SPRING R0140031 4-
RX Unit (Lot.1-59: Replaced by RX-2 Unit)
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
