Vertex Standard VXR-7000 Service Manual

81VXR-7000 UHF Service Manual
PCB with Components CS2389702 VERS. A (USA/NA & Except EIA/CE)
CS2389703 VERS. A ( EIA/CE )
CS2389704 VERS. BS1 (USA/NA & Except EIA/CE)
CS2389705 VERS. BS1 (EIA/CE)
CS2389706 VERS. D (USA/NA & Except EIA/CE)
CS2389707 VERS. D (EIA/CE)
C 3001 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A F1
C 3002 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B e2
C 3003 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A2
C 3004 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A A2
C 3006 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F2
C 3007 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A E1
C 3008 CHIP TA.CAP. 1.5uF 16V TEESVA1C155M8R K78120020 1- B e2
C 3009 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A A2
C 3010 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A E1
C 3011 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E1
C 3012 CHIP CAP. 0.033uF 16V R GRM188R11C333KA01D K22124801 1- B e2
C 3013 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VERS. D 147- A A1
C 3014 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1-146 A A1
C 3014 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 VERS. A 147- A A1
C 3014 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 VERS. BS1 147- A A1
C 3014 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VERS. D 147- A A1
C 3015 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A A2
C 3016 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B b2
C 3017 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A2
C 3018 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A A2
C 3019 CHIP TA.CAP. 0.1uF 35V TEESVA1V104M8R K78160025 1- B e3
C 3020 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VERS. A 1- A E1
C 3020 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VERS. BS1 62- A E1
C 3020 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VERS. D 1- A E1
C 3021 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E1
C 3022 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e3
C 3023 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E2
C 3024 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 VERS. A 1- A E1
C 3024 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217 VERS. BS1 62- A E1
C 3024 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 VERS. D 1- A E1
C 3025 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E1
C 3027 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A A1
C 3028 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A2
C 3029 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VERS. A 1- A E2
C 3029 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VERS. BS1 62- A E2
C 3029 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VERS. D 1- A E2
C 3030 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E1
C 3031 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A A1
C 3032 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b2
C 3033 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 VERS. A 1- A E1
C 3033 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 VERS. BS1 62- A E1
C 3033 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VERS. D 1- A E1
C 3034 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 VERS. A 1- A B3
C 3034 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 VERS. BS1 62- A B3
C 3034 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 VERS. D 1- A B3
C 3035 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 VERS. A 1- A B3
C 3035 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 VERS. BS1 62- A B3
C 3035 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 VERS. D 1- A B3
C 3036 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A A2
C 3037 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VERS. A 1- A C2
C 3037 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 VERS. BS1 62- A C2
C 3037 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 VERS. D 1- A C2
C 3038 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B f2
C 3039 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E1
C 3040 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2
C 3041 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D1
C 3042 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A B2
C 3043 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f2
C 3044 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 VERS. A 1- A D1
C 3044 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 VERS. BS1 62- A D1
C 3044 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VERS. D 1- A D1
RX-2 Unit (Lot.60-)
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
