82 VXR-7000 UHF Service Manual

RX-2 Unit (Lot.60-)

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE

LAYADR

Parts List

C 3045 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A D1

C 3046 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f1

C 3047 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A A2

C 3048 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A D1

C 3049 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A C2

C 3052 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A D1

C 3053 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217

VERS. A

1- A D1

C 3053 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217

VERS. BS1

62- A D1

C 3053 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215

VERS. D

1- A D1

C 3054 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A B2

C 3056 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A D1

C 3057 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 3058 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A D1

C 3060 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. A

1- A D1

C 3060 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. BS1

62- A D1

C 3060 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205

VERS. D

1- A D1

C 3061 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 3062 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B2

C 3063 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A B2

C 3064 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201

VERS. A

1- A D1

C 3064 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201

VERS. BS1

62- A D1

C 3065 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203

VERS. A

1- A D1

C 3065 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203

VERS. BS1

62- A D1

C 3065 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. D

1- A D1

C 3066 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A B2

C 3067 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208

VERS. A

1- A D1

C 3067 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208

VERS. BS1

62- A D1

C 3067 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. D

1- A D1

C 3068 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B e2

C 3069 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. A

1- A D1

C 3069 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. BS1

62- A D1

C 3069 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. D

1- A D1

C 3071 CHIP CAP. 5pF 50V CH GRM1882C1H5R0CZ01D K22174206 1- A B2

C 3072 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. A

1- A D1

C 3072 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204

VERS. BS1

62- A D1

C 3072 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205

VERS. D

1- A D1

C 3073 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B e2

C 3074 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e3

C 3075 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A D1

C 3077 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C2

C 3078 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e3

C 3079 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A C1

C 3080 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- A C1

C 3081 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B1

C 3082 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e3

C 3083 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A B1

C 3084 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B1

C 3085 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 3086 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217

VERS. A

1- A C1

C 3086 CHIP CAP. 18pF 50V CH GRM1882C1H180JA01D K22174217

VERS. BS1

62- A C1

C 3086 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215

VERS. D

1- A C1

C 3087 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f3

C 3088 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 3089 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213

VERS. A

1- A B1

C 3089 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213

VERS. BS1

62- A B1

C 3089 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211

VERS. A

1- A B1

C 3090 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B1

C 3092 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c2

C 3093 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c2

C 3094 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A E3

C 3096 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b3

C 3097 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A E3

C 3099 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D3

C 3100 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1- A E3

C 3102 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a3

C 3103 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B a3

C 3104 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- B d3
