94 VXR-7000 UHF Service Manual

CNTL Unit

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE

LAYADR

Parts List

C 4059 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B f1

C 4060 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f2

C 4061 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g6

C 4062 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g6

C 4063 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B f1

C 4064 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B f1

C 4065 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d6

C 4066 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d6

C 4067 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d6

C 4068 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d6

C 4069 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- B g4

C 4070 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B f4

C 4071 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- B g4

C 4072 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B f3

C 4073 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B f1

C 4074 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 4075 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 4076 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 4077 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 4078 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 4079 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 4080 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 4081 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B e1

C 4082 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B f3

C 4083 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f2

C 4084 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- B f4

C 4085 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B f2

C 4086 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B f3

C 4087 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d6

C 4088 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1-18 B d6

C 4088 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 19- B d6

C 4089 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B d6

C 4090 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 4091 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B e3

C 4092 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f3

C 4093 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f3

C 4094 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- B e5

C 4095 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B d5

C 4096 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B e5

C 4097 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- A D2

C 4098 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- B c4

C 4099 CHIP CAP. 0.0039uF 50V B GRM188B11H392KA01D K22174830 1- B e2

C 4100 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B e4

C 4101 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c4

C 4102 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A D2

C 4104 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B e4

C 4105 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1- B e2

C 4106 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e4

C 4107 CHIP CAP. 1uF 10V B GRM21BB11A105KA01L K22100802 1- B c4

C 4108 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e4

C 4110 CHIP CAP. 0.0015uF 50V B GRM188B11H152KA01D K22174811 1- B e1

C 4111 CHIP CAP. 1uF 10V B GRM21BB11A105KA01L K22100802 1- B e4

C 4112 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c6

C 4113 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c6

C 4114 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c6

C 4115 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g6

C 4116 CHIP CAP. 0.015uF 25V B GRM39B153K25PT K22144805 1- A E2

C 4117 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- B d4

C 4118 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B e2

C 4119 CHIP CAP. 0.0033uF 50V B GRM188B11H332KA01D K22174815 1- A E1

C 4120 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A E2

C 4121 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c5

C 4122 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c5

C 4124 CHIP TA.CAP. 1.5uF 20V TEESVA1D155M8R K78130013 1- B e4

C 4125 CHIP CAP. 0.0015uF 50V B GRM188B11H152KA01D K22174811 1- B d1

C 4126 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B g5

C 4127 CHIP CAP. 1uF 10V B GRM21BB11A105KA01L K22100802 1- B e4
