93VXR-7000 UHF Service Manual

CNTLUnit

Parts List

PCB with Components CS2388704 VERS. D

(USA/NA & Except EIA/CE)

CS2388705 VERS. D

(EIA/CE)

CS2388706 VERS. A

(USA/NA & Except EIA/CE)

CS2388707 VERS. A

(EIA/CE)

CS2388708 VERS. BS1

(USA/NA & Except EIA/CE)

CS2388709 VERS. BS1

(EIA/CE)

C 4001 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g2

C 4002 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g2

C 4003 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g2

C 4004 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h1

C 4005 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h1

C 4006 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h1

C 4007 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B h3

C 4008 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h1

C 4009 AL.ELECTRO.CAP. 100uF 25V RE2-25V101MH3# K40149028 1- A A5

C 4010 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h3

C 4011 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h1

C 4012 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B h4

C 4013 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g3

C 4014 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h2

C 4015 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g3

C 4016 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h2

C 4017 AL.ELECTRO.CAP. 10uF 25V RC2-25V100ME1# K40149012 1- A A3

C 4018 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h2

C 4019 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B i3

C 4020 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h2

C 4021 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B h2

C 4022 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B i4

C 4023 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A A4

C 4024 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B h3

C 4025 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g2

C 4026 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B g1

C 4027 AL.ELECTRO.CAP. 10uF 16V ECEV1CS100SR K48120001 1-75 A A3

C 4027 AL.ELECTRO.CAP. 10uF 16V EEE1CS100SR K48120023

76-184

AA3

C 4027 AL.ELECTRO.CAP. 10uF 16V UWX1C100MCL2GB K48120016 185- A A3

C 4028 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B g1

C 4029 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g1

C 4030 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- A B2

C 4031 AL.ELECTRO.CAP. 470uF 16V RE3-16V471MG3# K40129066 1- A B3

C 4032 CHIP CAP. 56pF 50V CH GRM1882C1H560JA01D K22174229 1- B f1

C 4033 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g3

C 4034 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B g2

C 4035 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B h2

C 4036 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- B g4

C 4037 CHIP TA.CAP. 2.2uF 25V TEESVA1E225M8R K78140020 1- B h4

C 4038 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B f1

C 4039 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B g2

C 4040 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B g2

C 4041 CHIP TA.CAP. 33uF 10V TEESVB21A336M8R K78100047 1- B g1

C 4042 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B h4

C 4043 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B g2

C 4044 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B g2

C 4045 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B g2

C 4046 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B h4

C 4047 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B h2

C 4048 CHIP CAP. 0.047uF 16V B GRM39B473K16PT K22124804 1- B g4

C 4049 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A B2

C 4050 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B g2

C 4051 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- B f1

C 4052 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g6

C 4053 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g6

C 4054 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B g6

C 4055 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1-18 B h6

C 4055 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 19- B h6

C 4056 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B g2

C 4057 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B g3

C 4058 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- B g2

DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE

LAYADR
