EVX-534/-539 VHF Service Manual 6
Parts List
REF. DESCRIPTION VALUE MFR’s DESIG VXSTD P/N
 EVX-534FRONTCASEASSY  CB6928000
 EVX-539FRONTCASEASSY  CB6929000
 FRONTCASESUBASSY   CB6641000
 KNOB(VOL)   RA125100B
 KNOB(CH)   RA125110B
 WASHER   RA1396900
 BUSH 2pcs  RA125090A
 SPMOUNTPLATE   S5000322
 SPEAKER 16-ohm  M4090204
 WIREASSY   T9207535A
 MIC/SPCAPASSY   CB6642000
 BINDHEADTAPTITE-B 2pcs M2X5 U24105001

 CHASSISASSY   CB6643000
 RUBBERPACKING  (CHASSIS) RA1448500
 RUBBERBOOTS   RA1458000
 SHEET  (6x6) RA037690B
 PANHEADSCREW 2pcs M2X2.5(3) U07225001
 BINDHEADTAPTITE-B 2pcs 2X10(3) U24110001
 MAINUNIT  EVX-534 CB6938000
   EVX-539 CB6950000
F1001 CHIPFUSE  3.15A,36V FHC16322ADTP Q0000118
F1301 CHIPFUSE  1.25A,36V FCC16132ABTP Q0000109
MC1001 MIC.ELEMENT  PF0-1055P M3290045
Q1513 FET  RQA0011DNS#G0 G3070507
S1001 TACTSWITCH  EVQPUB02K N5090167
S1002 TACTSWITCH  EVQP8403M N5090173
S1003 TACTSWITCH  EVQPUB02K N5090167
S1004 TACTSWITCH  EVQPUB02K N5090167
S1006 ROTARYSWITCH  TP7NBPC1614.7FRY-10115 N0190198
TH1001 THERMISTOR  TH054B473FR G9090150
VR1001 POT.  TP76N975N13.5FB503RY10034 J60800314
X1001 XTAL 32.768kHz 4809995L1832.768KHZ H0103407
X1501 TCXO 19.2MHz TTS27NSC-A719.2MHZ H9501380
XF1501 XTALFILTER  1D50807GQ850.85 H1102493
 SHIELDCASECOVER  (FET) RA125020A
 SPONGERUBBER  (LIGHTGUIDE) RA1580800
 PORONSHEET  (16X10) RA1534700
 NUT 2pcs (C065) RA090590A
 PANHEADTAPTITE-B 5pcs M2X5 U44105001
 DISPLAYUNIT   CB6927000
 BINDHEADTAPTITE-B 2pcs 2X10(3) U24110001
 PANHEADTAPTITE-B 2pcs M2X15(3) U44115001
Whenreplaceachipfuse,
usethepartofthesametypeandvalue.
