PWC – 450
PureWaterCooler
Copyright 2011 Vertex Water Products
6.1 Remove dispensing control panel by pulling
outward from the bottom. Once the panel is loose,
remove by pulling down.
6.2 Remove circuit board cover, by removing (2)
screws from the back and pulling the cover off.
6.3 Disconnect (5) electrical connectors from board.
6.4 Remove (2) screws holding circuit board to panel.
6.5 Re-assemble in reverse order
6. Remove/Replace Circuit Board
