-VERTIGO COMBAT-V07-ENG.DOCX - FRAME SECTION
Carrer Argenteria 8-10, Pol. Ind. Riera de Caldes. 08184 Palau-Solità i Plegamans (Barcelona - Spain) T + 34 931 70 16 55.
21 Remove and disconnect throttle device (two nuts, the two bolts
are welded to the support)
22 Remove radiator protection
23 Remove fixation flanges and disconnect cylinder head water pipe
24 Remove radiator and its adjusting support (one upper bolt and
two lower bolts)
