88
-VERTIGO COMBAT-V07-ENG.DOCX - FRAME SECTION
Carrer Argenteria 8-10, Pol. Ind. Riera de Caldes. 08184 Palau-Solità i Plegamans (Barcelona - Spain) T + 34 931 70 16 55.
3.6.4 Front fork assembly
1 Image of the motorcycle with the front assembly assembled
2 Initial view of the front fork assembly process
3 Screw lower plate 4 bolts
4 Assemble shaft, lower plate and rods
