Vertigo CAMO WORKS - Swingarm Disassembly

86
SERVICE MANUAL
-VERTIGO COMBAT-V07-ENG.DOCX - FRAME SECTION
Vertigo.
Carrer Argenteria 8-10, Pol. Ind. Riera de Caldes. 08184 Palau-Solità i Plegamans (Barcelona - Spain) T + 34 931 70 16 55.
3.6.3 Swingarm disassembly
SWINGARM DISASSEMBLY
1 Remove chain
2 Remove rear wheel nut and shaft. The brake caliper is released
3 Remove rocker fixation bolt and swingarm
4 Release rear brake pump tube fixation
