Vertilux VTi CELTIC - Weight Capacity by Installation Type; Single Motor Configurations; Double Motor Configurations

3
vertilux.com
© 2019. Vertilux, Ltd. All Rights Reserved. Last revised: February 2019.
Weight capacity depending on the type of installation
1. Single motor with single master carrier
(One Way)
2. Single motor with double master carrier
(Center Open)
3. Double motor with single master carrier
(One Way)
4. Double motor and double master carrier
(Center Open)
Max. weight*:
1 Nm Motor: 40 kg I 88 lb
2 Nm Motor: 60 kg I 132 lb
Track size: 12 m I 39 ft
Max. weight*:
1 Nm Motor: 50 kg I 110 lb
2 Nm Motor: 75 kg I 165 lb
Track size: 12 m I 39 ft
Max. weight*:
1 Nm Motor: 70 kg I 154 lb
2 Nm Motor: 105 kg I 231 lb
Track size: 12 m I 39 ft
Max. weight*:
1 Nm Motor: 90 kg I 198 lb
2 Nm Motor: 135 kg I 298 lb
Track size: 12 m I 39 ft
*The maximum weight capacity is calculated under optimal circumstances. Actual results may vary.
Specifications are subject to change without notice.
