Ports with RJ11 interface allow to control the motor either via dry contacts or RS485. The motor
can be managed from a PC or with a home automation system.
This option allows to operate multiple motors at the same time with a RS485, dry contacts or a PC.
Wiring
Group control
Antenna
Port 1 Port 2
Programming button
Motor A
Motor B
Control with a RS485, dry
contacts or a PC
LED Indicator
AC 100V-240V
Serial B
Manual COM line
Manual UP line
Manual STOP line
Manual DOWN line
Serial A
From P2
Motor A
To P1
Motor B
To Next Page
