Long-run Models:
MODEL
1K
2K
3K
CAPACITY*
1000 VA / 800 W
2000 VA / 1600 W
3000 VA / 2400 W
INPUT
Voltage
Range
Low Line Transfer
85VAC/75VAC/65VAC/55VAC± 5% or 160VAC/140VAC/120VAC/110VAC± 5%
(Ambient Temp.<35
0
C)
( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
Low Line Comeback
95VAC/85VAC/75VAC/65VAC or 175VAC/155VAC/135VAC/125VAC ± 5 %
(Ambient Temp.<35
0
C)
( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0)
High Line Transfer
145 VAC ± 5 % or 300 VAC ± 5 %
High Line Comeback
140 VAC ± 5 % or 290 VAC ± 5 %
Frequency Range
40Hz ~ 70 Hz
Phase
Single phase with ground
Power Factor
≧ 0.99 @ nominal voltage (input voltage)
OUTPUT
Output voltage
100/110/115/120/127VAC or 200/208/220/230/240VAC
AC Voltage Regulation
± 1% (Batt. Mode)
Frequency Range
47 ~ 53 Hz or 57 ~ 63 Hz (Synchronized Range)
Frequency Range (Batt. Mode)
50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz
Overload
Ambient Temp.<35
0
C
105%~110%: UPS shuts down after 10 minutes at battery mode or transfer to bypass when the utility is
normal
110%~130%: UPS shuts down after 1minute at battery mode or transfer to bypass when the utility is
normal
>130%:UPS shuts down after 3 seconds at battery mode or transfer to bypass when the utility is normal
Current Crest Ratio
3:1
Harmonic Distortion
≦ 3 % THD (linear load); ≦ 6 % THD (non-linear load)
Transfer
Time
AC Mode to Batt. Mode
Zero
Inverter to Bypass
4 ms (Typical)
Waveform (Batt. Mode)
Pure Sinewave
EFFICIENCY
AC Mode
88%
89%
90%
Battery Mode
83%
87%
88%
BATTERY
Battery Numbers
2
3
4
6
8
6
8
Charging Current
1.0A/2.0A/4.0A/6.0 A
Charging Voltage
27.4 VDC ±
1%
41.0VDC ±
1%
54.7 VDC
± 1%
82.1VDC
± 1%
109.4VDC
± 1%
82.1 VDC
± 1%
109.4VDC ± 1%
PHYSICAL
Dimension, D X W X H
282 x 145 x 220 (mm)
397x 145 x 220(mm)
Net Weight (kgs)
4.1
4.1
6.8
6.8
6.8
7.4
7.4
ENVIRONMENT
Operation Humidity
20-90 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 50dBA @ 1 Meter
MANAGEMENT
Smart RS-232 or USB
Supports Windows® 2000/2003/XP/Vista/2008/7/8, Linux, Unix and MAC
Optional SNMP
Power management from SNMP manager and web browser
* Derate capacity to 80% of capacity in Frequency converter mode or when the output voltage is adjusted to 200VAC/208VAC or when
the ambient temperature from 40
0
C to 50
0
C.
**Product specifications are subject to change without further notice.
