CABINET DIMENSIONAL DATA
REV : 1
REV DATE : 08/17
DPN004058
Page :1 /1
Form No.: DPN001040_REV4
LIEBERT PFD
53 1/8"
1349mm
18" (457mm) min. clearance
required for proper air flow
on both air inlet sides
24" (610mm) min. clearance recommended
for component access
Removable Panel - Access to
refrigeration components,
electrical components and connections
Top Air Discharge
2"
51mm
3"
76mm
4 3/4"
121mm
23 9/16"
599mm
O
1/2"
13mm
Typical 6 places
2 1/8"
53mm
35 15/16"
913mm
5 TON HIGH AMBIENT/QUIET-LINE OUTDOOR CONDENSING UNIT
TOP AIR DISCHARGE
5 5/16"
135mm
38 5/16"
973mm
Air Inlet
44 11/16"
1136mm
3 11/16"
94mm
53 1/4"
1352mm
32 1/8"
816mm
Anchorage Plan
60Hz
PFD067A-H
PFDZ67A-L
MODEL
NUMBERS
MODULE WEIGHT
lbs. (kg) net.
488 (222)
Air Inlet
Bottom View of Unit
