Vertiv NetSure 7100 Series User Manual

Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
69
Table 3: Shunt Inputs – EIB
Shunt Input
EIB
Pin No.
Factory
Wiring
Default
Function
Customer
Defined Function
Sh1
J5-2 + --
none
J5-1 – --
Sh2
J5-4 + --
none
J5-3 – --
Sh3
J5-6 + --
none
J5-5 – --
Table 4: Voltage Inputs – EIB
Voltage Input
EIB
Pin No.
Default
Function
1 J6-1
Battery
Block
Monitoring
2
J6-2
3 J6-3
4 J6-4
5 J6-5
6 J6-6
7 J7-1
8 J7-3
