Make Bay-to-Bay Communications Cable Connections
Refer to Bay-to-Bay Communications Cable Connections in the MAKING ELECTRICAL CONNECTIONS section
of the Installation Instructions (IM582127000) for a complete procedure.
The bays are interconnected using standard Cat5 communications cables. Supplemental bays are provided
with a 25’ cable. Refer to Figure 39 for a bay-to-bay cable diagram.
NOTE! Maximum combined length of the Cat5 communications cables is 328’ (100m) per industry
standards.
Installing Bay-to-Bay Busbars (582127000 List 1 with List 2 / List 3) (for system mounted
in a relay rack)
Refer to Installing Bay-to-Bay Busbars (582127000 List 1 with List 2 / List 3) in the MAKING ELECTRICAL
CONNECTIONS section of the Installation Instructions (IM582127000) for a complete procedure.
When 582127000 List 3 and/or List 2 is ordered, bay-to-bay busbars and hardware are provided for system
power connections between distribution cabinets. Interconnect per Figure 40.
Installing Bay-to-Bay Busbars (582127000 List 1 with List 7 / List 8) (for system mounted
in an enclosure)
Refer to Installing Bay-to-Bay Busbars (582127000 List 1 with List 7 / List 8) in the MAKING ELECTRICAL
CONNECTIONS section of the Installation Instructions (IM582127000) for a complete procedure.
When 582127000 List 8 and/or List 7 is ordered, bay-to-bay busbars and hardware are provided for system
power connections between distribution cabinets. Interconnect per Figure 41.
