Chapter 1 Introduction 1
NetSure 801 AG1 Power Supply System User Manual
Chapter 1 Introduction
This chapter introduces the model information, overview and components of the NetSure 801 AG1 power supply
system.
1.1 Model Information
The model information of the NetSure 801 AG1 power supply system is shown in Figure 1-1.
NetSure G 1
Version
Region. A: Asia-Pacific region
Output power of the rectifier. The output power of rectifier: 5800W
Brand name of the power supply system
801
A
The number of the rectifier in the typical power system. G: 16
Figure 1-1 Model information of the power supply system
The model information of the NetSure 801 AG1-T1 rectifier is shown in Figure 1-2.
NetSure G 1
System version
Cabinet height. T: 2.2 m
Version
Region. A: Asia-Pacific region
Output power of the rectifier. The output power of rectifier: 5800W
Brand name of the power supply system
801
A
T 1
The number of the rectifier in the typical power system. G: 16
-
Figure 1-2 Model information of the recifiter cabinet
The model information of the PD48/2000DD DC distribution cabinet is shown in Figure 1-3.
PD
2000
D
D
Power distribution cabinet
-
Power distribution mode: DC power distribution
X1
48
/
Configuration
Output current (2000A)
Output voltage (-48V)
Cabling type: U - top cabling; D - bottom cabling
Figure 1-3 Model information of the DC distribution cabinet
1.2 Overview
The NetSure 801 AG1 power supply system is a new generation of telecom power supply with exceptional reliability
and performance. It is designed by Vertiv incorporating years of experience in development and equipment operation
on power network. The NetSure 801 AG1 power supply system is composed of DC distribution cabinet, rectifier
cabinet, controller, rectifier and options.
The number of DC distribution cabinet and rectifier cabinet can be configured according to customer requirement.
The capacity of the system can be expanded to 5760A at most. The system composed of one DC distribution cabinet
