14. RS 232 PARAMETERS
External devices connected to RS 232C have to be supplied from the
same mains and common electric shock protection. It prevents from
appearing a potential difference between zero leads of the two devices.
This notice does not apply to the devices that do not use zero leads.
Transmission parameters:
x Baud rate - 2400 – 38400 bit / s
x Data bits - 7,8
x Stop bits - 1,2
x Parity control - no, even, odd
There are four ways of sending data via RS232 interface:
xManually – after pressing
,
xAutomatically – after stabilizing the indication over -LO- threshold
xContinuously – after it is activated in parameter or by a command
sent via RS232
xOn external request - see - „List of scale - computer commands”.
The indication can be sent as:
xstable – the indication is sent after the scale stabilizes.
xany – the indication is sent immediately after pressing the
key,
this state is assign with <?> in the printout.
14.1. Printout type
This parameter is to select the type of printout.
Procedure:
x Enter the submenu <P2.Prnt> and then:
- 25 -
