8
Ⅳ. Technical Parameters
Mode
lItem
Smart1
Max. feeding width
13inch(330mm)
Max. cutting width
12inch(305mm)
Cutting thickness
≤1mm
linear velocity
10-300mm/s
Right tool pressure
10-500gf
Left tool pressure
50-500gf
Buffer
1M
Cutting precision
±0.1mm
Interface
U-DISK/USB /Bluetooth4.2ble
Supporting systems
Mac、Windows 、Android 5.1/iOS 11.0 above
Adapter
INPUT:AC100-240V,50-60Hz,48W;
OUTPUT:DC24V ,2A
Ⅴ.Product Assembly Steps
a. Keep 20 inches clear of obstructions before and after.
