tank tread kit • 8
Inventor’s Guide insert
accessories
motion accessories
tank tread kit, continued
Once the chain of tread links is securely in place, connect the first
and last link to make a continuous loop.
You can now slightly loosen the screws holding the bogey wheel
assemblies and tensioner in place. Slide the tensioner and the
bogey wheel assemblies to tighten the chain of tread links. If the
tread links are loose, they’ll come off once the robot is in motion.
Limited 90-day Warranty
This product is warranted by Innovation One against manufacturing defects in material and workmanship under
normal use for ninety (90) days from the date of purchase from authorized Innovation One dealers. For complete
warranty details and exclusions, check with your dealer.
Innovation One, Inc.
350 North Henderson Street
Fort Worth, TX 76102
08/05
Printed in China
0405
