When the camcorder is connected to the PC
through the USB for the rst time, the PC will
automatically install the UVC-related drivers.
• Built-in Microphone.
Built-in microphone, pick up distance up to six
meters, high sensitivity, low noise oor.
• 1080P Full HD.
With the new generation of Panasonic 1/2.7
inch, 2.07 million effective pixels of high-quality
HD CMOS sensors, you can achieve high-quality
images with a maximum resolution of 1920x1080.
• High Frame Rate.
1080P output frame rate up to 60fps.
• 72.5° Wide-angle lens + 16x Digital Zoom.
With a 72.5° high quality super-lens lens, the
optical zoom can be up to 12 times and supports
16x digital zoom (optional).
• Low illumination
The application of 2D and 3D noise reduction
algorithm greatly reduces the image noise.
Even under the condition of ultra-low illumination,
it still keeps the picture clean and clear, and the
SNR of image is as high as 55dB.
• Remote Control
Through the RS232 and RS485 serial ports,
the camera can be controlled remotely.
PRODUCT SPECIFICATION
SIGNAL SYSTEM
1080p/60 (optional), 1080p/50 (optional),
1080p/30, 1080p/25, 720p/60, 720p/50, 720p/30,
720p/25.
SENSOR
1/2.7 inch, CMOS, Effective pixels: 2.07 million.
SCANNING MODE
Progressive.
LENS
12x, f3.5mm ~ 42.3mm, F1.8 ~ F2.8.
DIGITAL ZOOM
16x (optional).
MINIMUM ILLUMINATION
0.5Lux @ (F1.8, AGC ON).
SHUTTER
1/30s ~ 1/10000s.
WHITE BALANCE
Auto, Indoor, Outdoor, One Push, Manual, VAR.
BACKLIGHT COMPENSATION
Support.
DIGITAL NOISE REDUCTION
2D, 3D digital noise reduction.
SIGNAL NOISE RATIO
≥55dB.
HORIZONTAL ROTATION RANGE
±170°.
VHD-V71U2
DATASHEET - MANUAL
> NOTE
> ABOUT PRODUCT
> PACKING LIST
When you unpack, check that all the supplied
accessories are included:
• Electric Safety. Installation and operation must
accord with electric safety standard.
• Use caution to transport. Avoid stress, vibration
or soakage in transport, storage and installation.
• Polarity of power supply. The power supply of
this product is +12V, the max electrical current
is 2A. Polarity of the power supply plug drawing
shows as below.
FEATURES
• New appearance
Worm and worm drive design, new appearance,
mini-style, two-color optional.
• USB 3.0
Supports UVC protocol, compatible with USB
2.0 and USB 3.0, USB 3.0 supports up to
1920x1080p/60 output, and USB 2.0 supports
up to 960x540p/60 output.
• Electric Safety. Installation and operation must
accord with electric safety standard.
• Use caution to transport. Avoid stress, vibration
or soakage in transport, storage and installation.
• Polarity of power supply. The power supply of
this product is +12V, the material) damage.
Make sure there is no obstacle within rotation
range. Please never power on before installation is
completed.
• Do not dismantle the camera. We are not
responsible for any unauthorized modication or
dismantling. Max electrical current is 2A. Polarity
of the power supply plug drawing shows as below.
Specic frequencies of electromagnetic eld
may affect the image of the camera!
NAME
Camera
AC Power Adaptor
Power Cable
Serial Cable
Remote Control
User Manual
USB 3.0 Cable
QUALITY
1
1
1
1
1
1
1
