S1
Sealing ring 1 (for sandwich roof panels)
15x36
type
L seal
art. no.
remark
S1-680
680
400117
A
S1-980
980
402033
A
S1-1180
1180
408027
A
Remark
A Sealing ring for suction pad groove 15x15mm, compensates up to 5mm profiling.
S2
Sealing ring 2 (for sandwich wall panels)
15x32
type
L seal
art. no.
remark
S2-980
980
402041
A
S2-1180
1180
408028
A
S2-1470
1470
402034
A
Remark
A Sealing ring for suction pad groove 15x15mm, compensates up to 3mm profiling.
