Vibra SJ-E Series - Names of Component Parts; Main Unit

2. Names of Component Parts
2.1 Main Unit
Round-pan types (SJ-220E, SJ-420E, SJ-620E)
Square-pan types ( SJ-1200E, SJ-2200E, SJ-4200E, SJ-6200E, SJ-12KE)
Operation keys
See page 7.
Level
For checking
t
he level of the
balance
T
urn the adjusters
until the bubble rests
in the center of the
red circle.
A
djusters
Round-pan type: Total of two, one on either
side of the unit’s front
Square-pan type: Total of four, one on either
side at front and rear
AC adapter
connector
Measurement
pan
Liquid-crystal
display (LCD)
See page 6.
RS232C
connector
(Option)
Front View (round-pan type)
Rear view
Square-pan
type
Measurment pan
・SJ-1200E:170mm×140mm
・SJ-2200E〜SJ-12KE:180mm×160mm
5
