VR9500 Hardware Description
© 2019 Vibration Research Corporation is a registered trademark in the United States and other countries.
1
1 VR9500 Hardware Description
1.1 Installing the Controller
A NOTE indicates important information that helps you make better use of your controller.
A CAUTION indicates a potential for property damage, personal injury, or death. .
Installation Precautions
CAUTION: Before performing any of the following procedures, read and follow the safety
instructions.
CAUTION: If the equipment is used in a manner not specified by the manufacturer, the protection provided
by the equipment may be impaired.
CAUTION Observe the following points before performing the procedures in this section:
·
Ensure that the rack or cabinet housing the device is adequately secured to prevent it from becoming
unstable and/or falling over.
·
Ensure that the power source circuits are properly grounded.
·
Observe and follow the service markings. Do not service any device except as explained in the system
documentation. Opening or removing covers marked with a triangular symbol with a lightning bolt may
cause electrical shock. These components are to be serviced by trained service technicians only.
·
Ensure that the power cable, extension cable, and/or plug are not damaged.
·
Ensure that the device is not exposed to water.
·
Ensure that the device is not exposed to radiators and/or heat sources.
·
Ensure that the cooling vents are not blocked.
·
Do not push foreign objects into the device, as it may cause a fire or electric shock.
·
Use the device only with approved equipment.
·
Allow the device to cool before removing covers or touching internal equipment.
·
Ensure that the device does not overload the power circuits, wiring, and over-current protection. To
determine the possibility of overloading the supply circuits, add together the ampere ratings of all switches
installed on the same circuit as the device. Compare this total with the rating limit for the circuit.
·
Do not install the device in an environment where the operating ambient temperature might exceed 50ºC
(122ºF).
·
Ensure that the airflow around the front, sides, and back of the device is not restricted.
Site Requirements
The VR9500 can be mounted in a standard equipment rack or placed on a tabletop, or mounted on the wall.
Before installing the device, verify that the site selected for the device meets the following site requirements:
·
Power — The device is installed within 1.5 m (5 feet) of a grounded, easily accessible outlet 220/110 VAC,
50/60 Hz.
·
General — Ensure that the power supply is correctly installed.
·
Clearance — There is adequate frontal clearance for operator access. Allow clearance for cabling, power
connections, and ventilation.
·
Cabling — Cabling is routed to avoid sources of electrical noise such as radio transmitters, broadcast
amplifiers, power lines, and fluorescent lighting fixtures.
·
Ambient Requirements — The ambient device operating temperature range is 0 to 50°C (32 to 122°F) at a
relative humidity of up to 95%RH , non-condensing. Verify that water or moisture cannot enter the device
case.
·
Do not operate this product near volatile or flammable materials.
