1) Insert one end of the test lead into the input jack of the calibrator
and connect the other end to the output of the user ’ s instrument as
shown in the following diagram:
2) Press the key 〔 INPUT/OUTPUT
INPUT/OUTPUT
INPUT/OUTPUT
INPUT/OUTPUT
〕 when the symbol ‘ INPUT ’
appears in the display. It denotes that the calibrator is in an input
state.
3) P ress the key 〔 FUN
FUN
FUN
FUN
〕 to select the desired measurement functio n
when the corresponding unit and the type of RTD appear in the
display.
4) T o use the function of RTD, press the key 〔 RANG
RANG
RANG
RANG
〕 to select the
corresponding type of RTD.
5) T he display indicates ‘ 000.0 ’ first, denoting a wait followed by
displaying the measured result. The refreshing rate of displaying
the measurement is about once per second if the measured value
exceeds the measuring range, the display will indicate the symbol ‘ -
OL- ’ .
6) P ress the key 〔 ℃ /
/
/
/
℉ 〕 to select the temperature unit ‘ ℃ / ℉ ’ .
7.
7.
7.
7.
Other
Other
Other
Other
Features
Features
Features
Features
T he following operation makes it possible for the calibrator to change its
automatic power-off function.
1) C ut off the power supply of the calibrator.
2) P ress the key 〔 POWER
POWER
POWER
POWER
〕 to make a full screen display. T hen
release the key 〔 POWER
POWER
POWER
POWER
〕 immediately followed by pressing the
key 〔 RANG
RANG
RANG
RANG
〕 when the calibrator gets into a maintenance state. Th e
+
+
+
+
INPUT
Hi
OUTPUT
-
-
-
-
HiLoLo
30V
MAX
30V
MAX
S
S
S
S
