The topics are listed in the table below. Only topics marked with a * are visible in case of 2 day history.
TOTAL YIELD* The cumulative yield since the last history reset
MAX PANEL VOLTAGE The maximum panel voltage since the last history reset
MAX BATTERY VOLTAGE The maximum battery voltage since the last history reset
MIN BATTERY VOLTAGE
The minimum battery voltage since the last history reset.
(Only available for MPPT software version >= 1.17)
The last 4 errors since the last history reset.
The number of blocks in the lower right of the screens determines
which error is currently shown with 1 block being the latest and 4
MAX POWER* The maximum power per day
MAX PANEL VOLTAGE The maximum panel voltage per day
MAX BATTERY CURRENT The maximum battery current per day
MAX BATTERY VOLTAGE The maximum battery voltage per day
MIN BATTERY VOLTAGE The minimum battery voltage per day
BULK TIME The time spend in bulk per day
ABSORPTION TIME The time spend in absorption per day
FLOAT TIME The time spend in float per day
LAST ERROR
The last 4 errors per day
The number of blocks in the lower right of the screens determines
which error is currently shown.
Settings
By pressing SETUP for 2 seconds in the status menu, the settings menu is entered. Here, the settings of the MPPT and MPPT Control
can be viewed and changed. First the topic is shown and when SELECT is pressed, the corresponding value is shown. When SELECT
TO EDIT is OFF, the value is shown before it can be changed by pressing SELECT again. When SELECT TO EDIT is ON, the current
value is shown and a new value can immediately be selected. When LOCK SETUP is ON, settings only be changed after setting LOCK
SETUP to off.
