ds3-ds4: Setting charge voltages
ds3-ds4
Absorption
voltage
Float
voltage
Storage
Voltage
Absorption
Time
(hours)
Suitable for
dS3=off
dS4=off
(default)
14.4
28.8
57.6
13.8
27.6
55.2
13.2
26.4
52.8
8
Gel Victron Deep
Discharge
Gel Exide A200
AGM Victron Deep
Discharge
dS3=on
dS4=off
14.1
28.2
56.4
13.8
27.6
55.2
13.2
26.4
52.8
8
Gel Victron Long
Life (OPzV)
Gel Exide A600
(OPzV)
Gel MK battery
dS3=off
dS4=on
14.7
29.4
58.8
13.8
27.6
55.2
13.2
26.4
52.8
5
AGM Victron Deep
Discharge
Tubular plate or
OPzS batteries in
semi-float mode
AGM spiral cell
dS3=on
dS4=on
15.0
30.0
60.0
13.8
27.6
55.2
13.2
26.4
52.8
6
Tubular plate or
OPzS batteries in
cyclic mode
Batteries with high antimony content can typically be charged with a lower absorption
voltage than batteries with low antimony content. (Please refer to our book “Electricity on
Board” downloadable from our website www.victronenergy.com for details and suggestions
about charging batteries). Contact your battery supplier for the correct charge voltages and
change (with VE-configure) the voltage settings if required.
The default charge current setting is 75% of the maximum charge current. This current will be
too high for most applications.
For most battery types the optimal charge current is 0.1-0.2x the battery capacity.
ds5: Inverter frequency off = 50Hz on = 60Hz
ds6: Search Mode off = off on = on
ds7: AC input current limit off = 12 Amp on = 4 Amp
Store the settings by moving Dip switch 8 to “on” and back to “off”.
