Step 2: Exemplary settings
Example 1 is the factory setting (since factory settings are entered by computer, all DIP switches of a new product are set to
‘off’ and do not reflect the actual settings in the microprocessor).
Example 1 (factory setting):
8, 7 GEL 14,4V
6 Absorption time: 8 hours
5 Adaptive charging: on
4 Dynamic current limit: off
3 UPS function: on
2 Voltage: 230V
1 Frequency: 50Hz
Example 2:
8, 7 OPzV 14,1V
6 Absorption time: 8 h
5 Adaptive charging: on
4 Dyn. current limit: off
3 UPS function: off
2 Voltage: 230V
1 Frequency: 50Hz
Example 3:
8, 7 AGM 14,7V
6 Absorption time: 8 h
5 Adaptive charging: on
4 Dyn. current limit: on
3 UPS function: off
2 Voltage: 240V
1 Frequency: 50Hz
Example 4:
8, 7 Tubular-plate 15V
6 Absorption time: 4 h
5 Fixed absorption time
4 Dyn. current limit: off
3 UPS function: on
2 Voltage: 240V
1 Frequency: 60Hz
To store the settings after the required values have been set: press the 'Down' button for 2 seconds (lower button to the right of
the DIP switches). The temperature and low-battery LEDs will flash to indicate acceptance of the settings.
The DIP switches can be left in the selected positions, so that the ’other settings’ can always be recovered.
6. MAINTENANCE
The Quattro does not require specific maintenance. It will suffice to check all connections once a year. Avoid moisture and
oil/soot/vapours, and keep the device clean.
