NOTICE!
Product damage when bending directly at the connector
Extreme bending directly at the connector may cause
damage to pipe and connector and leaks.
– To avoid damage, choose a bending point with sufficient
distance to the connector.
Viega Smartpress multilayer pipes in the dimensions 16–32 mm can be
bent by hand with a bending radius of 5 x d or with a bending tool with
the following radii:
d Bending radius x d
16 2.0
20 2.3
25 3.0
32 3.5
40 4.0
50 4.5
63 4.5
The recommended bending tools for dimensions d 16 and 20 are the
models 5331 and 5331.2.
3.3.2
Shortening the pipes
For information about tools, also see Ä Chapter 3.2.3 „Required
tools“ on page 18.
Cut the protective pipe to length using the protective pipe cutter
(model 5341).
Dimensions 16–25 mm
Handling
