Viessmann AC-Box - Connection with AC-Box Connection Accessories

10
Connection with AC-Box connection accessories
1.
4x
2.
4.
2x
5.
2x
3.
2x
2x
Fig.4
Note
Thermally insulate the connections of the AC-Box and
the heat pump with vapour diffusion-proof adhesive
tape.
A to
D
Hydraulic connection lines: See the following
table
Installation sequence
Hydraulic connection (cont.)
5675 895 GB
Installation
