29
Pos. Part
0001
High efficiency circulation pump M1 with plug
sÖ
A
0002
High efficiency circulation pump M2 with plug
sÖ
B
0003 2-way motorised ball valve
0004 Ball valve G 1¼ with 2-way motorised ball valve
0005 3-way diverter valve
0006 Plate heat exchanger
0007 Plate heat exchanger
0008 Connection bend, heating/cooling circuit return
0009 3-way diverter valve pipe connection piece
0010 Triple pipe bend
0011 Pipe connection piece for high efficiency heating/cooling circuit pump
0012 Pipe connection piece for high efficiency primary circuit pump
0013 Pipe, heating/cooling circuit flow
0014 Pipe sections, primary circuit flow (brine)
0015 Pipe sections, primary circuit return (brine)
0016 Pipe sections, primary circuit return (brine)
0017 Pipe connection piece for hydraulic connection line to the heat pump (brine)
0018 Pipe for hydraulic connection line to the heat pump (brine)
0019 Pipe sections, heating/cooling circuit flow
0020 Pipe sections, heating/cooling circuit return
0021 Gaskets (set)
0022 Locking stay
0023 Spring clip
0024 O-rings 7 20 x 3.5 mm (set)
0025 Air vent valve G ⅜
Parts lists
Hydraulics (cont.)
5675 895 GB
Components
