Viessmann ECV Series - Page 14

Set-up
14
Minimum Clearances
Recommended minimum service clearances
Side
mm inches
Rear: 610 24
Top: 610 24
Right side: 610 24
Left side: 610 24
Front: 1220 48
All clearances are measured from boiler enclosure.
Minimum clearances to combustibles
Side
mm inches
Rear: 25 1
Top: 150 6
Right side: 25 1
Left side: 150 6
Front: 150 6
Floor: non combustible
Above clearances apply to all ECV boilers.
(all measurements from boiler enclosure)
5167 450 v1.4
