Additional Information
43
Troubleshooting Guide (continued)
Fan runs, pilot lights, burner short cycles Remedy
Thermostat anticipator t oo low Set anticipator to 0.9A on mercury bulb thermostats
No ground or weak ground connection on pilot Replace ground wire on pilot burner
Pilot on wrong burner Ensure five-port burner is used (see Fig. 13).
Lack of proper air f low Remove any obstruction from vent or vent terminal, replace
power v enter if deteriorated, clean heat exchanger
Excessive wind Relocate vent terminal, protect from wind with fence or
shrub
Ignition module defective Replace ignition control module
5167 450 v1.4
