Viessmann NC-Box User Manual

27
Dimensions
Length mm 520
Width mm 580
Height mm 420
Weight
■
Dry kg approx. 32
■
With water kg approx. 37
Permiss. ambient temperature
■
Operation °C 2 to 30
■
Storage and transport °C –30 to 60
Hydraulic connections
Primary circuit flow (NC-Box brine inlet/outlet) G 1½
Flow/return, heating/cooling circuit, separate cooling circuit G 1
Flow/return, secondary circuit to the heat pump G 1
Power supply 1/N/PE 230 V/50 Hz
Specification
Specification
5675 869 GB
Appendix

Viessmann NC-Box Specifications

General

Brand	Viessmann
Model	NC-Box
Category	Heating System
Language	English
