Set-up
13
Boiler Set-up and Location
1. Remove the combustion chamber
door and ensure all transportation
wrapping is taken off.
Remove package containing the
nameplate of the boiler, the levelling
bolts, and the sight glass for later
installation.
Installation without domestic
hot water tank
2. Mount four levelling bolts into boiler
base plate.
3. Position boiler and arrange lev elling
bolts so boiler is slightly inclined to
the rear.
Boiler must be installed on
non-combustible floor if not installed
on a boiler stand or on a DHW tank.
Installation on domestic
hot water tank
Installation Instructions
Domestic Hot Water Tank
5167 404 v1.9
IMPORTANT
To Next Page
